Side 1/2

WP3 - Outdoor Utility Enclosure

Specifications:

• NEMA4/4X,IP66-11Ratedenclosureforoutdooruse.

• Lightweightmoldedfiberglassreinforcedpolyesterenclosureiscorrosionresistantanddoesnotcontainhalogens.

• Lockablestainlesssteellatches.

• Integralflangessimplifywallorpolemounting.

• Applications:PowerSupplies,BatteriesandAuxiliarymodules.

• Productweight:7.0lbs.(3.18kg).

• Shippingweight:8.3lbs.(3.76kg).

Installation Instructions:

1. Removebackplanefromenclosurepriortomounting(donotdiscardhardware).

2. Markanddrilldesiredinletsontheenclosuretofacilitatewiring(Fig. 1, pg. 1).

3. Mountunitindesiredlocation.Markanddrillholestolineupwiththetopandbottomholesoftheenclosureflange.

 Secureenclosurewithappropriatefasteners(Fig. 2 , pg. 1).

4. Mountcircuitboardstobackplane.

5. Mountbackplanetoenclosurewithhardware.

6. TofacilitatewireentryutilizeweathertightNEMA4ratedconnectors,bushingsandcable.

Fig. 1

Bottom of Enclosure

Suggested Locations

for Wiring Inlets

Wall Mount Installation

1-Placeunitatthedesiredlocationandsecurewithmountingscrews

(not included) (Fig. 2, pg. 1).

Fig. 2

Pole Mounting Using Optional Pole Mount Kit PMK1 (not included):

Thisinstallationshouldbemadebyqualifiedservicepersonnel.Thisproductcontainsnoserviceableparts.PMK1isintended

forusewithAltronixoutdoorratedpowersuppliesoraccessorieshousedinWP1,WP2,WP3andWP4enclosures.Brackets

aredesignedforusewiththeWormgearQuickReleaseStraps(twoincluded).

1. Threadone(1)wormgearquickreleasestrapthroughtheslotsonthebackofamountingbracket(Fig. 3, pg. 1).

2. OncethedesiredheightofthetopPoleMountbracketisachieved,tightenthestrapsdownbyslidingopenendofthe 

 strapthroughthelockingmechanismonthestrap,thentightenthescrewwithflatheadscrewdriveror5/16”hex 

 socketdriver(Fig. 3, pg. 1).

3. Attachthebottombrackettotheenclosurebyinsertingboltsthroughtheflangeoftheenclosureandintothebracket, 

 tighteningboltswitha7/16”hexsocket(Fig. 4, pg. 1).

Fig. 3

Fig. 4

Fig. 5

Altronixisnotresponsibleforanytypographicalerrors.

14058thStreet,Brooklyn,NewYork11220USA,718-567-8181,fax:718-567-9056

website:www.altronix.com,e-mail:info@altronix.com,MadeinU.S.A.

IIWP3-Rev.051112 L22N

MEMBER

1.61”

(40.894mm)

3.96”

(100.584mm)

5.60”

(142.24mm)

10-32 X 0.375” (9.525mm)

BRASS INSERT (X4)

STAINLESS STEEL PIANO HINGE

11.32” (287.528mm)

13.32”

(338.328mm)

PADLOCK LATCH ATTACHED

WITH RIVETS (Ø 0.375” (9.52mm) PADLOCK EYE).

10.75” (273.05mm)

10.00” (254mm)

8.25” (209.55mm)

10.25”

(260.35mm)

12.00”

(304.8mm)

13.50”

(342.9mm)

10-32 X 0.25” (6.35mm)

BRASS INSERT (X2)

Ø 0.32 (8.128mm) MOUNTING HOLE

TYP. 4 PLACES

12.75”

(323.85mm)

8.00” (203.2mm)

Enclosure Dimensions (H x W x D approximate):

13.3”x11.3”x5.6”(338.1mmx287.3mmx142mm)

4. Threadthesecondwormgearquickreleasestrapthroughtheslotsonthe

 backofthebottommountingbracket(Fig. 6, pg. 2).

5. Mountenclosureontothetopbracketbyinsertingboltsthroughflangeoftheenclosure

 andintothebracket,tighteningboltswitha7/16”hexsocket(Fig. 6, pg. 2).

6. Tightenthestrapsofthebottombracketdownbyslidingtheopenendof

 thestrapthroughthelockingmechanismonthestrap,thentightenscrew

 withflatheadscrewdriveror5/16”hexsocketdriver(Fig. 7/7a, pg. 2).

7. Clipexcessstraps.

Fig. 7 - 2” to 8”(50.8mm to 203.2mm) Fig. 7a - 5” (127mm)

diameter round pole square pole

Fig. 6

Produkspesifikasjoner

Merke:	Altronix
Kategori:	Ikke kategorisert
Modell:	WP3
Vekt:	3180 g
Bredde:	287 mm
Dybde:	142 mm
Høyde:	338 mm
Materiale:	Polyester
Produktfarge:	Grå
Internasjonal beskyttelses (IP)-kode:	IP66
