Side 1/3
- 1 -
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2016
Thank you for selecting American Standard...
the benchmark of fine quality for over 100 years.
To ensure that your installation proceeds smoothly-please read
these instructions carefully before you begin.
RECOMMENDED TOOLS
1
2
3 3a
M965761 (8/16)
INSTALL FAUCET
SECURE FAUCET AND MAKE WATER SUPPLY CONNECTIONS
INSTALL POP-UP DRAIN
COLONY
®
PRO
CENTERSET
LAVATORY FAUCET
INSTALLATION
INSTRUCTIONS
7075.200
7075.202
7075.205
Phillips ScrewdriverPlumbers’ Putty or CaulkingAdjustable Wrench Hex Wrench (2 mm)Channel Locks
Certied to comply with ANSI A112.18.1M
CAUTION
Turn off hot and cold water
supplies before begining.
• Insert FAUCET (1) and POP-UP CABLE (2) through mounting
holes of Sink or Mounting Surface.
• Secure FAUCET (1) with ATTACHMENT NUTS (2) supplied.
(HAND TIGHTEN).
• Connect water supply to FAUCET (1) with 1/2" IPS FLEXIBLE
SUPPLIES (3) or 3/8"O.D. BULL-NOSE RISERS (4). Use adjustable
wrench to tighten connections. Do not over tighten. Be careful
not to kink copper supply when bending. Use tubing cutter to
cut to proper length.
NOTE: FLEXIBLE SUPPLIES HAVE TO BE PURCHASED SEPARATELY
• Apply a bead of putty to
underside of FLANGE (1).
• Drop FLANGE (1) into LAVATORY
DRAIN (2). From below assemble
RUBBER GASKET (3), METAL
WASHER (4) and LOCK NUT (5).
Do not tighten.
1
2
4
3
1
FERRULE
COUPLING NUT
1
1
3
4
2
5
