Side 1/22

User Manual

Manuel d’ utilisation

Since everyone’s ears are unique, make sure to try out all sizes.

Only with the perfect size of ear tips will you enjoy a snug fit and

optimum sound quality.

Charging for first time use

Charging the battery before use is recommended but not required. The

headphones ship pre-charged however initial charge will vary. Connect

cable to the USB slot of any PC or Mac.

The status indicator will be red while charging and will turn off when

fully charged.

Headset Features

Pair mode

Playing Music

Begin with headphones powered off. Push and hold NC Button for 6-8

seconds until LED indicator alternates red and blue. You are now in

pair mode. See your phone/music device manual for pair instructions.

* Note

- If the pairing is not successful, switch off headphones by pushing the

MFB for 3 seconds, and then re-pair according to the steps outlined

above.

- After pairing is successful, paired devices will remember each other.

Unless pairing information is deleted, there is no need to pair again.

- The headphones will automatically connect with the latest paired

device. If you want to pair with another Bluetooth device, switch off

the Bluetooth function of the current Bluetooth device, and then pair

and connect it with the new Bluetooth device according to steps

outlined above.

Volume Up

Volume Down

Forward

LED indicator

Backward

MFB

EN EN

Keys Function

Volume up

Volume down

Play next song

Play previous

PAIRING For NC on/off and pairing headset function

Power on / off / Play/Pause/Phone call function

Micro USB

MFB

Active Noise-Canceling Operation

• Press the NC button to toggle NC mode on/off

• When NC activates, the green LED will turn on. When NC

mode is off, the green LED will turn off.

Headset Mode Care and maintenance

Standby mode:

• Double click MFB to use voice dial function

• Press the MFB and NC buttons to use the last number

redial function

• Hold the Vol- and Forward buttons for 3~5 seconds to clear

the paired list

Incoming call (ring) mode:

• Press the MFB to accept phone calls

• Hold the MFB to reject incoming calls

In call active mode:

• Press Vol+ or Vol- to adjust volume

• Hold the MFB when you hear a beeping tone to

toggle calls between your headset and cellular phone

• Press the MFB to end a call

• Hold Vol+ and Vol- simultaneously to mute the microphone

• Keep dry and do not store in a damp place

• Do not put the product in direct sunlight for extended

periods of time or in hot areas.

• High temperature will shorten the life of the electronic

device, destroy the battery and distort certain plastic.

• Do not expose the product to extreme cold.

• Do not disassemble the product.

• Do not drop the headphones.

• Do not use chemicals or detergents to clean the product.

EN EN

Produkspesifikasjoner

Merke:	Antec
Kategori:	hodetelefon
Modell:	BXH-200NCWHI
Produkttype:	Hodetelefoner
Bredde:	23 mm
Dybde:	15 mm
Høyde:	40 mm
Bruksanvisning:	Ja
Bluetooth:	Ja
Bluetooth-versjon:	3.0+HS
Tilkoblingsteknologi:	Trådløs
Akustisk system:	Lukket
Trådløst mottakergrensesnitt:	3,5 mm
Batteriteknologi:	Lithium-Ion (Li-Ion)
Batteriladetid:	8 timer
Produktfarge:	Hvit
Strøm-LED:	Ja
Frekvensbånd og driftskanaler:	2.4 GHz
Rekkevidde trådløs ruter:	10 m
Bæremåte:	Ørekrok
Hodetelefonsfrekvens:	20 - 20000 Hz
Hodetelefonssensitivitet/hodetelefonsfølsomhet:	30 dB
Øresammenkobling:	Intraaural
Kontinuerlig lyd-playbacktid:	8, 200 timer
Indikator for batteriopplading:	Ja
