Side 1/78

Version 1.0

Published January 2018

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure and

compensation for any other reasonably foreseeable loss or damage caused by our

goods. You are also entitled to have the goods repaired or replaced if the goods fail

to be of acceptable quality and the failure does not amount to a major failure. If

you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard

International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Produkspesifikasjoner

Merke:	Asrock
Kategori:	Hovedkort
Modell:	B360M-HDV
Bredde:	226 mm
Dybde:	188 mm
Maksimal oppløsning:	4096 x 2160 piksler
Strømkildetype:	ATX
Antall USB 2.0-porter:	2
Antall HDMI-porter:	1
Hodetelefonutganger:	1
Sertifisering:	FCC, CE, ErP/EuP
HDCP:	Ja
Maksimalt internminne:	32 GB
Grafikkadapterfamilie:	Intel
Komponent for:	PC
LAN-kontroller:	Intel® I219-V
Støttede minnetyper:	DDR4-SDRAM
Hovedkort formfaktor:	Micro ATX
Antall minnespor:	2
BIOS-type:	UEFI AMI
ACPI-versjon:	6.0
USB 2.0-tilkoblinger:	2
Intel® Extreme Memory Profile (XMP):	Ja
12V strømkontakt:	Ja
Antall DVI-D-porter:	1
Kabler inkludert:	SATA
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Harmonisert system (HS)-kode:	84733020
prosessorprodusent:	Intel
DirectX-versjon:	12.0
Antall PS/2-porter:	1
Støttede Windows operativsystemer:	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
TPM-tilkobling:	Ja
Minnekanaler:	Tokanals
Ubufret minne:	Ja
Kompatible prosessorserier:	Intel Core i3, Intel Core i5, Intel Core i7
Prosessorstøpsel:	LGA 1151 (kontakt H4)
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Gigabit Ethernet
Antall SATA III-tilkoblinger:	6
BIOS minnestørrelse:	128 Mbit
Understell inngrepstilkobling:	Ja
Støttede minneklokkehastigheter:	2133,2400,2666 MHz
Thermal Power-prosessor (maks):	95 W
Systemkort kretsoppsett:	Intel® B360
Minnesportype:	DIMM
Hovedkort-chipsettfamilie:	Intel
Lyd-utgang kanaler:	7.1 kanaler
Antall COM-tilkoblinger:	1
ATX strømtilkobling (24-pin):	Ja
Drivere medfølger:	Ja
Antall understellsviftetilkoblinger:	2
CPU viftetilkobling:	Ja
Guide for hurtiginstallering:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	4
Lydtilkobling på fremsiden:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-kontakter:	1
Wake-on-LAN-forberedt:	Ja
PCI Express x16 (Gen 3.x) slots:	1
PCI Express x1 (Gen 3.x) slots:	2
Verktøy inkludert:	Ja
