Asrock H97M Bruksanvisning

Asrock Hovedkort H97M

Les nedenfor 📖 manual på norsk for Asrock H97M (95 sider) i kategorien Hovedkort. Denne guiden var nyttig for 12 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 6.5 brukere

Last ned PDF

Side 1/95

H97MH97M

Version 1.1

Published July 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Produkspesifikasjoner

Merke:	Asrock
Kategori:	Hovedkort
Modell:	H97M
Bredde:	- mm
Dybde:	- mm
Bluetooth:	Nei
Wi-Fi:	Nei
Maksimal oppløsning:	1920 x 1200 piksler
Strømkildetype:	ATX
Antall USB 2.0-porter:	4
Antall HDMI-porter:	1
Sertifisering:	FCC, CE, WHQL, ErP/EuP
Maksimalt internminne:	16 GB
Lydbrikke:	Realtek ALC892
Grafikkadapterfamilie:	Intel
Komponent for:	PC
LAN-kontroller:	Atheros AR8171
Støttede minnetyper:	DDR3-SDRAM
Hovedkort formfaktor:	Micro ATX
Antall minnespor:	2
BIOS-type:	EFI AMI
ACPI-versjon:	1.1
USB 2.0-tilkoblinger:	2
Diskret grafikkstøtte:	Ja
Antall DVI-D-porter:	1
Kabler inkludert:	SATA
Antall VGA (D-Sub)-porter:	1
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
prosessorprodusent:	Intel
DirectX-versjon:	11.1
Antall viftetilkoblinger:	Ja
Antall PS/2-porter:	1
Støttede Windows operativsystemer:	Ja
RAID-nivåer:	0, 1,5, 10
TPM-tilkobling:	Ja
Minnekanaler:	Tokanals
Ubufret minne:	Ja
Maksimalt antall SMP-prosessorer:	1
Kompatible prosessorserier:	Intel Celeron, Intel Pentium
Prosessorstøpsel:	LGA 1150 (kontakt H3)
Støttede lagringsgrensesnitt:	SATA III
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Gigabit Ethernet
Antall SATA III-tilkoblinger:	6
BIOS minnestørrelse:	64 Mbit
Understell inngrepstilkobling:	Ja
Støttede minneklokkehastigheter:	1066,1333,1600 MHz
Systemkort kretsoppsett:	Intel® H97
PCI Express x16 (Gen 2.x) slots:	1
Minnesportype:	DIMM
Hovedkort-chipsettfamilie:	Intel
Lyd-utgang kanaler:	7.1 kanaler
Videokontakter:	HD Graphics 4000
On-board grafikkort:	Nei
Antall COM-tilkoblinger:	1
ATX strømtilkobling (24-pin):	Ja
PCI-slots:	2
Drivere medfølger:	Ja
Antall understellsviftetilkoblinger:	3
Intel® Core i3/i5/i7/i9 series:	i3-4xxx, i5-4xxx, i7-4xxx
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	4
PC-ytelsesovervåkning:	CPU, FAN, Power supply, Temperature
Form for nedkjøling:	Passiv
CPU viftetilkobling:	Ja
Maks. skjermkortminne:	1792 MB
Guide for hurtiginstallering:	Ja
S/PDIF-utport:	Ja
Lydtilkobling på fremsiden:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-kontakter:	1
Støtter parallellprosesseringsteknologi:	2-Way CrossFireX, Quad-GPU CrossFireX
S/PDIF ut-tilkobling:	Ja
EPS strømtilkobling (8-pin):	Ja
Wake-on-LAN-forberedt:	Ja
PCI Express x16 (Gen 3.x) slots:	1
Parallell port via intern header:	Ja
