User Manual

Version 1.1

Published October 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Produkspesifikasjoner

Merke:	Asrock
Kategori:	Hovedkort
Modell:	B85M-ITX
Bredde:	- mm
Dybde:	- mm
Maksimal oppløsning:	1920 x 1200 piksler
Strømkildetype:	ATX
Antall USB 2.0-porter:	4
Antall HDMI-porter:	1
Hodetelefonutganger:	1
HDCP:	Ja
Maksimalt internminne:	16 GB
Komponent for:	PC
LAN-kontroller:	Atheros AR8171
Antall eSATA-porter:	1
Støttede minnetyper:	DDR3-SDRAM
Hovedkort formfaktor:	Mini-ITX
Antall minnespor:	2
BIOS-type:	UEFI AMI
ACPI-versjon:	1.1
USB 2.0-tilkoblinger:	2
Antall DVI-D-porter:	1
Kabler inkludert:	SATA
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
prosessorprodusent:	Intel
Antall viftetilkoblinger:	Ja
Antall PS/2-porter:	1
TPM-tilkobling:	Ja
Minnekanaler:	Tokanals
Ubufret minne:	Ja
Maksimalt antall SMP-prosessorer:	1
Kompatible prosessorserier:	Intel Celeron, Intel Pentium
Prosessorstøpsel:	LGA 1150 (kontakt H3)
Støttede lagringsgrensesnitt:	SATA III
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Fast Ethernet, Gigabit Ethernet
Antall SATA III-tilkoblinger:	4
BIOS minnestørrelse:	64 Mbit
Understell inngrepstilkobling:	Ja
Støttede minneklokkehastigheter:	1066,1333,1600 MHz
Systemkort kretsoppsett:	Intel® B85
Minnesportype:	DIMM
Støttede minnemodulkapasiteter:	2GB, 4GB, 8GB
Hovedkort-chipsettfamilie:	Intel
Lyd-utgang kanaler:	7.1 kanaler
ATX strømtilkobling (24-pin):	Ja
PCI Express x16 slots:	1
Antall understellsviftetilkoblinger:	1
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
PCI Express sporversjon:	3.0
CPU viftetilkobling:	Ja
Guide for hurtiginstallering:	Ja
S/PDIF-utport:	Ja
Lydtilkobling på fremsiden:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-kontakter:	1
