Side 1/86

Version 1.0

Published June 2015

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

Produkspesifikasjoner

Merke:	Asrock
Kategori:	Hovedkort
Modell:	FATAL1TY Z170 GAMING-ITX/AC
Bredde:	170 mm
Dybde:	170 mm
Bluetooth:	Ja
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth-versjon:	4.0
USB-kontakttype:	USB Type-A, USB Type-C
Strømkildetype:	ATX
Antall HDMI-porter:	2
Hodetelefonutganger:	1
Sertifisering:	- FCC, CE, WHQL\n- ErP/EuP ready (ErP/EuP ready power supply is required)
HDCP:	Ja
Antall DisplayPorts:	1
Maksimalt internminne:	32 GB
Forhåndsinstallert programvare:	Software and BIOS\tSoftware\n- ASRock F-Stream\n- ASRock Disk Health Report\n- ASRock USB Key\n- ASRock Key Master\n- ASRock APP Charger\n- ASRock XFast LAN\n- ASRock XFast RAM\n- ASRock Fast Boot (Fast Boot, Restart to UEFI)
DisplayPort-versjon:	1.2
Lydbrikke:	Realtek ALC1150
LAN-kontroller:	Intel® I219-V
Støttede minnetyper:	DDR4-SDRAM
Hovedkort formfaktor:	Mini-ITX
Antall minnespor:	2
BIOS-type:	UEFI AMI
ACPI-versjon:	5.0
USB 2.0-tilkoblinger:	1
Mini PCI Express-spor (halv lengde):	1
Intel® Extreme Memory Profile (XMP):	Ja
Antall SATA Express-kontakter:	1
Kabler inkludert:	SATA
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Bærekraftsertifikater:	RoHS
prosessorprodusent:	Intel
Antall PS/2-porter:	1
RAID-nivåer:	0, 1,5, 10
Minnekanaler:	Tokanals
Ubufret minne:	Ja
Kompatible prosessorserier:	Intel Celeron, Intel Pentium
Prosessorstøpsel:	LGA 1151 (kontakt H4)
Støttede lagringsgrensesnitt:	M.2, SATA III
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Gigabit Ethernet
Antall SATA III-tilkoblinger:	6
Understell inngrepstilkobling:	Ja
Støttede minneklokkehastigheter:	2133,2400,2800,2933,3200,3600,3866,4000 MHz
Systemkort kretsoppsett:	Intel® Z170
Minnesportype:	DIMM
Hovedkort-chipsettfamilie:	Intel
Lyd-utgang kanaler:	7.1 kanaler
ATX strømtilkobling (24-pin):	Ja
Drivere medfølger:	Ja
Antall understellsviftetilkoblinger:	2
Intel® Core i3/i5/i7/i9 series:	i3-6xxx, i5-6xxx, i7-6xxx
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	6
CPU viftetilkobling:	Ja
Guide for hurtiginstallering:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	1
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	1
S/PDIF-utport:	Ja
Lydtilkobling på fremsiden:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-kontakter:	1
Antall M.2 (M)-spor:	1
Wake-on-LAN-forberedt:	Ja
PCI Express x16 (Gen 3.x) slots:	1
Clear CMOS-knapp:	Ja
