Asrock G31M-S Bruksanvisning

Asrock Hovedkort G31M-S

Les nedenfor 📖 manual på norsk for Asrock G31M-S (45 sider) i kategorien Hovedkort. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/45

G31M-GS / G31M-S

User Manual

Version 1.1

Published September 2008

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identification or explanation and to the owners’ benefit, without intent to infringe.

Disclaimer:Disclaimer:

Disclaimer:

Specifications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or fitness for a particular purpose.

In no event shall ASRock, its directors, officers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of profits, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in

California, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

ContentsContents

Contents

1 Introduction1 Introduction

1 Introduction

......................................................................................................

...................................................

5 5

1.1 Package Contents.......................................................... 5

1.2 Specifications ................................................................ 6

1.3 Motherboard Layout ........................................................ 10

1.4 I/O Panel......................................................................... 11

2 Installation2 Installation

2 Installation

..........................................................................................................

.....................................................

12 12

2.1 Screw Holes ................................................................... 12

2.2 Pre-installation Precautions............................................ 12

2.3 CPU Installation.............................................................. 13

2.4 Installation of Heatsink and CPU fan ............................... 15

2.5 Installation of Memory Modules (DIMM) ......................... 16

2.6 Expansion Slots (PCI and PCI Express Slots) ..................... 17

2.7 Jumpers Setup ............................................................... 18

2.8 Onboard Headers and Connectors .................................. 20

2.9 SATAII Hard Disk Setup Guide ........................................ 24

2.10 Serial ATA (SATA) / Serial ATAII (SATAII) Hard Disks

Installation...................................................................... 25

2.11 Driver Installation Guide .............................................. 25

2.12 Untied Overclocking Technology .................................... 25

3 BIOS S3 BIOS S

3 BIOS S

ETUP UTILITYETUP UTILITY

ETUP UTILITY

....................................................................................

..........................................

26 26

3.1 Introduction ..................................................................... 26

3.1.1 BIOS Menu Bar..................................................... 26

3.1.2 Navigation Keys .................................................... 27

3.2 Main Screen ................................................................... 27

3.3 Smart Screen ................................................................. 29

3.4 Advanced Screen ............................................................ 30

3.4.1 CPU Configuration ................................................ 30

3.4.2 Chipset Configuration ............................................ 32

3.4.3 ACPI Configuration ................................................ 35

3.4.4 IDE Configuration .................................................. 36

3.4.5 PCIPnP Configuration ........................................... 38

3.4.6 Floppy Configuration ............................................. 39

3.4.7 Super IO Configuration .......................................... 39

3.4.8 USB Configuration ................................................ 40

3.5 Hardware Health Event Monitoring Screen...................... 41

3.6 Boot Screen ................................................................... 42

3.6.1 Boot Settings Configuration ................................... 42

3.7 Security Screen.............................................................. 43

3.8 Exit Screen .................................................................... 44

Produkspesifikasjoner

Merke:	Asrock
Kategori:	Hovedkort
Modell:	G31M-S
Bredde:	244 mm
Dybde:	191 mm
Strømkildetype:	ATX
Antall USB 2.0-porter:	4
Hodetelefonutganger:	1
Sertifisering:	FCC, CE
Maksimalt internminne:	8 GB
Kompatible operativsystemer:	Microsoft Windows 2000 / XP / XP 64-bit / Vista / Vista 64-bit
Lydbrikke:	Realtek ALC662
Hovedkort formfaktor:	Micro ATX
Antall minnespor:	2
BIOS-type:	AMI
Antall SATA-tilkoblinger:	4
USB 2.0-tilkoblinger:	2
CD/AUX lydinngang:	Ja
Antall parallelle ATA-tilkoblinger:	1
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
prosessorprodusent:	Intel
Antall viftetilkoblinger:	Nei
Antall PS/2-porter:	2
Prosessorstøpsel:	LGA 775 (Socket T)
Kommunikasjonsserieporter:	1
BIOS minnestørrelse:	32 Mbit
Lyd-utgang kanaler:	5.1 kanaler
ATX strømtilkobling (24-pin):	Ja
Diskettstasjonstilkobling:	Ja
PCI Express x16 slots:	1
PCI-slots:	2
PCI Express x1 slots:	1
Nettverksgrensesnitt:	PCIE x1 LAN
CPU viftetilkobling:	Ja
Grafikkontroller:	Intel Graphics Media Accelerator 3100
Maks. skjermkortminne:	384 MB
Lydtilkobling på fremsiden:	Ja
Kontrollergrensesnitt:	SATAII
Kontroll (2.) grensesnittype:	ATA100
