Asrock K7S8X R3.0 Bruksanvisning
Les nedenfor 📖 manual på norsk for Asrock K7S8X R3.0 (29 sider) i kategorien Hovedkort. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/29
1
K7S8X
K7S8XE
User Manual
Version 3.1
Published July 2003
Copyright©2003 ASRock INC. All rights reserved.
2
Copyright Notice:
No part of this manual may be reproduced, transcribed, transmitted, or translated in
any language, in any form or by any means, except duplication of documentation by
the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this manual may or may not be regis-
tered trademarks or copyrights of their respective companies, and are used only for
identification or explanation and to the owners’ benefit, without intent to infringe.
Disclaimer:
Specifications and information contained in this manual are furnished for informa-
tional use only and subject to change without notice, and should not be constructed
as a commitment by ASRock. ASRock assumes no responsibility for any errors or
omissions that may appear in this manual.
With respect to the contents of this manual, ASRock does not provide warranty of
any kind, either expressed or implied, including but not limited to the implied warran-
ties or conditions of merchantability or fitness for a particular purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from
any defect or error in the manual or product.
ASRock Website: http://www.asrock.com
3
Contents
1 Introduction.................................................... 4
1.1 Package Contents ........................................................... 4
1.2 Specifications ................................................................. 5
1.3 Motherboard Layout (K7S8X) ........................................ 7
1.4 Motherboard Layout (K7S8XE) ...................................... 8
1.5 ASRock I/O
TM
(K7S8X / K7S8XE) ................................... 9
2 Installation ...................................................... 10
2.1 Screw Holes ................................................................... 10
2.2 Pre-installation Precautions ............................................ 10
2.3 CPU Installation ............................................................... 11
2.4 Installation of Heatsink and CPU fan .............................. 11
2.5 Installation of Memory Modules (DIMM) .......................... 12
2.6 Expansion Slots .............................................................. 12
2.7 Jumpers Setup ................................................................ 13
2.8 Connectors ..................................................................... 15
3 BIOS Setup ...................................................... 17
3.1 BIOS Setup Utility ............................................................ 17
3.1.1 BIOS Menu Bar ..................................................... 17
3.1.2 Legend Bar ........................................................... 17
3.2 Main Menu ....................................................................... 18
3.3 Advanced, Security, Power, Boot, and Exit Menus ...... 20
4 Software Support ........................................... 21
4.1 Installing Operating System ............................................ 21
4.2 Support CD Information ................................................... 21
4.2.1 Running Support CD ............................................. 21
4.2.2 Drivers Menu ........................................................ 21
4.2.3 Utilities Menu ......................................................... 21
4.2.4 ASRock “PC-DIY Live Demo” Program ................. 21
4.2.5 Contact Information ............................................... 21
Appendix ........................................................... 22
1. Advanced Menu ............................................................. 22
2. Security Menu ................................................................. 26
3. Power Menu ................................................................... 27
4. Boot Menu ....................................................................... 28
5. Exit Menu ......................................................................... 29
