Asrock Z690 Steel Legend WiFi 6E/D5 Bruksanvisning

Asrock Hovedkort Z690 Steel Legend WiFi 6E/D5

Les nedenfor 📖 manual på norsk for Asrock Z690 Steel Legend WiFi 6E/D5 (115 sider) i kategorien Hovedkort. Denne guiden var nyttig for 6 personer og ble vurdert med 4.4 stjerner i gjennomsnitt av 3.5 brukere

Last ned PDF

Side 1/115

Version 1.0

Published January 2022

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Produkspesifikasjoner

Merke:	Asrock
Kategori:	Hovedkort
Modell:	Z690 Steel Legend WiFi 6E/D5
Bredde:	305 mm
Dybde:	244 mm
Bluetooth:	Ja
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax)
Antall HDMI-porter:	1
HDCP:	Ja
Antall DisplayPorts:	1
Maksimalt internminne:	128 GB
DisplayPort-versjon:	1.4
Lydbrikke:	Realtek ALC897
Grafikkadapterfamilie:	Intel
RAID-støtte:	Ja
Komponent for:	PC
LAN-kontroller:	Dragon RTL8125BG
Støttede minnetyper:	DDR5-SDRAM
Hovedkort formfaktor:	ATX
Antall minnespor:	4
BIOS-type:	UEFI AMI
ACPI-versjon:	6.0
USB 2.0-tilkoblinger:	2
Thunderbolt-headers:	1
PCI Express x16 (Gen 5.x) spor:	1
Beste Wi-Fi-standard:	Wi-Fi 6E (802.11ax)
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
prosessorprodusent:	Intel
Antall PS/2-porter:	1
RAID-nivåer:	0, 1,5, 10
Minnekanaler:	Tokanals
Ubufret minne:	Ja
Maksimalt antall SMP-prosessorer:	1
Kompatible prosessorserier:	Intel Core i3, Intel Core i5, Intel Core i7
Prosessorstøpsel:	LGA 1700
Støttede lagringsgrensesnitt:	M.2, SATA III
Antall lagringsdrivere som støttes:	11
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	2.5 Gigabit Ethernet
Antall SATA III-tilkoblinger:	8
BIOS minnestørrelse:	256 Mbit
Systemkort kretsoppsett:	Intel Z690
Minnesportype:	DIMM
Hovedkort-chipsettfamilie:	Intel
Lyd-utgang kanaler:	7.1 kanaler
ATX strømtilkobling (24-pin):	Ja
Antall understellsviftetilkoblinger:	5
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	4
CPU viftetilkobling:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	1
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	1
S/PDIF-utport:	Ja
Lydtilkobling på fremsiden:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-kontakter:	2
RGB LED pin header:	Ja
System management BIOS (SMBIOS)-versjon:	2.7
PCI Express x16 (Gen 4.x)-spor:	1
EPS strømtilkobling (8-pin):	Ja
Wake-on-LAN-forberedt:	Ja
PCI Express x16 (Gen 3.x) slots:	1
PCI Express x1 (Gen 3.x) slots:	2
