Side 1/20
Version 05-2021A
Before operating the device
Operating manual HVB 22, HVB 31 a. HVB 32 - Version 05-2021Apage 2
Before operating the device
HINWEIS: Read this operating manual through carefully!
It contains important information about installation, ambient
conditions and maintenance of the device. Keep this operating
manual for future use and for handover in the event of a
change of owner or operator. A PDF version of this manual can
be downloaded on the ASTRO website (there may be a more
recent version).
The ASTRO company confirms that the information in this
manual was correct at the time of printing, but it reserves the
right to make changes to the specifications, the operation of the
device and the operating manual without prior notice.
page 3
Contents
Operating manual HVB 22, HVB 31 a. HVB 32 - Version 01-2021A
Contents
Symbols and conventions used...........................................page 04
Intended use........................................................................page 05
Intended audience for this manual.......................................page 05
Device description...............................................................page 06
Important safety information................................................page 08
Warranty conditions.............................................................page 12
Performance description......................................................page 12
Disposal...............................................................................page 12
Installation...........................................................................page 13
Connection and start-up......................................................page 14
Configuration.......................................................................page 14
Troubleshooting...................................................................page 16
Maintenance and repair.......................................................page 16
Block diagram......................................................................page 17
Technical data.....................................................................page 18
Produkspesifikasjoner
| Merke: | Astro |
| Kategori: | fjernsynssignalforsterker |
| Modell: | HVB 22 |
| Vekt: | 800 g |
| Bredde: | 135 mm |
| Dybde: | 49 mm |
| Høyde: | 140 mm |
| Tilkobling: | F |
| Strømkildetype: | AC |
| Sertifisering: | EN 50083 -2 |
| Inngangsspenning: | 230 V |
| Antall porter: | 2 |
| Gevinst (bakovervei): | 22 dB |
| Produktfarge: | Sort, sølv |
| Strømforbruk (vanlig bruk): | 7.5 W |
| Driftstemperatur (T-T): | -15 - 55 °C |
| Inngangsfrekvens: | 50 Hz |
| Internasjonal beskyttelses (IP)-kode: | IP20 |
| Antall: | 1 |
| Frekvensområde (forovervei): | 85 - 1006 MHz |
| Frekvensområde (bakovervei): | 5 - 65 MHz |
| Støyfigur: | 5.5 dB |
| Gevinst (forovervei): | 25 dB |
