Asus B150 PRO GAMING D3 Bruksanvisning

Asus Hovedkort B150 PRO GAMING D3

Les nedenfor 📖 manual på norsk for Asus B150 PRO GAMING D3 (94 sider) i kategorien Hovedkort. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/94

Motherboard

B150 PRO GAMING D3

E10538

First Edition (V1)

July 2015

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

Offer to Provide Source Code of Certain Software

This product contains copyrighted software that is licensed under the General Public License (“GPL”),

under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software

Licenses. Such software in this product is distributed without any warranty to the extent permitted by the

applicable law. Copies of these licenses are included in this product.

Where the applicable license entitles you to the source code of such software and/or other additional data,

you may obtain it for a period of three years after our last shipment of the product, either

(1) for free by downloading it from http://support.asus.com/download

(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location

where you want to have it shipped to, by sending a request to:

ASUSTeK Computer Inc.

Legal Compliance Dept.

15 Li Te Rd.,

Beitou, Taipei 112

Taiwan

In your request please provide the name, model number and version, as stated in the About Box of the

product for which you wish to obtain the corresponding source code and your contact details so that we

can coordinate the terms and cost of shipment with you.

The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as

the corresponding binary/object code.

This offer is valid to anyone in receipt of this information.

ASUSTeK is eager to duly provide complete source code as required under various Free Open Source

Software licenses. If however you encounter any problems in obtaining the full corresponding source

code we would be much obliged if you give us a notication to the email address gpl@asus.com, stating

the product and describing the problem (please DO NOT send large attachments such as source code

archives, etc. to this email address).

iii

Contents

Safety information ...................................................................................... iv

About this guide ......................................................................................... iv

Package contents ....................................................................................... vi

B150 PRO GAMING D3 specications summary ..................................... vi

Chapter 1: Product introduction

1.1 Before you proceed ..................................................................... 1-1

1.2 Motherboard overview ................................................................. 1-1

1.3 Central Processing Unit (CPU) ................................................... 1-3

1.4 System memory ........................................................................... 1-7

1.5 Expansion slots .......................................................................... 1-15

1.6 Jumpers ...................................................................................... 1-17

1.7 Connectors ................................................................................. 1-18

1.8 Onboard LED .............................................................................. 1-29

1.9 Software support ........................................................................ 1-31

Chapter 2: BIOS information

2.1 Managing and updating your BIOS ............................................ 2-1

2.2 BIOS setup program .................................................................... 2-6

2.3 My Favorites ............................................................................... 2-13

2.4 Main menu .................................................................................. 2-14

2.5 Ai Tweaker menu ........................................................................ 2-16

2.6 Advanced menu ......................................................................... 2-24

2.7 Monitor menu ............................................................................. 2-32

2.8 Boot menu .................................................................................. 2-35

2.9 Tool menu ................................................................................... 2-40

2.10 Exit menu .................................................................................... 2-41

2.11 Installing an operating system ................................................. 2-42

Appendices

Notices .......................................................................................................A-1

ASUS contact information .......................................................................A-4

Produkspesifikasjoner

Merke:	Asus
Kategori:	Hovedkort
Modell:	B150 PRO GAMING D3
Bredde:	305 mm
Dybde:	236 mm
Maksimal oppløsning:	4096 x 2160 piksler
Strømkildetype:	ATX
Antall HDMI-porter:	1
Hodetelefonutganger:	1
Maksimalt internminne:	64 GB
Intel® Insider™:	Ja
Forhåndsinstallert programvare:	ASUS Utilities\nASUS EZ Update
Grafikkadapterfamilie:	Intel
Komponent for:	PC
LAN-kontroller:	Intel® I219-V
Støttede minnetyper:	DDR3-SDRAM
Hovedkort formfaktor:	ATX
Antall minnespor:	4
BIOS-type:	UEFI AMI
ACPI-versjon:	5.0
USB 2.0-tilkoblinger:	3
Diskret grafikkstøtte:	Ja
Kabler inkludert:	SATA
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
prosessorprodusent:	Intel
Antall PS/2-porter:	2
Støttede Windows operativsystemer:	Ja
TPM-tilkobling:	Ja
Minnekanaler:	Tokanals
Ubufret minne:	Ja
Maksimalt antall SMP-prosessorer:	1
Kompatible prosessorserier:	Intel Celeron, Intel Pentium
Prosessorstøpsel:	LGA 1151 (kontakt H4)
Støttede lagringsgrensesnitt:	SATA III, M.2
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Gigabit Ethernet
Antall SATA III-tilkoblinger:	6
BIOS minnestørrelse:	16 Mbit
Støttede minneklokkehastigheter:	1866,1333,1600 MHz
Minnesportype:	DIMM
Hovedkort-chipsettfamilie:	Intel
Lyd-utgang kanaler:	7.1 kanaler
Antall COM-tilkoblinger:	1
ATX strømtilkobling (24-pin):	Ja
PCI-slots:	2
Drivere medfølger:	Ja
Antall understellsviftetilkoblinger:	3
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	4
Form for nedkjøling:	Passiv
CPU viftetilkobling:	Ja
Maks. skjermkortminne:	512 MB
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	2
Støttet lagrings drive type:	HDD & SSD
S/PDIF-utport:	Ja
Intel® Turbo Boost Technology:	Ja
Intel® Quick Sync Video Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® InTru™ 3D Technology:	Ja
Lydtilkobling på fremsiden:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-kontakter:	1
Clear CMOS-pinner:	Ja
Antall M.2 (M)-spor:	1
Støtter parallellprosesseringsteknologi:	Quad-GPU CrossFireX
EPS strømtilkobling (8-pin):	Ja
PCI Express x16 (Gen 3.x) slots:	2
PCI Express x1 (Gen 3.x) slots:	2
