Asus P8Z77-V PRO/THUNDERBOLT Bruksanvisning

Asus Hovedkort P8Z77-V PRO/THUNDERBOLT

Les nedenfor 📖 manual på norsk for Asus P8Z77-V PRO/THUNDERBOLT (192 sider) i kategorien Hovedkort. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/192

Motherboard

P8Z77-V PRO/

THUNDERBOLT

E7309

First Edition

May 2012

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

Offer to Provide Source Code of Certain Software

This product may contain copyrighted software that is licensed under the General Public License (“GPL”)

and under the Lesser General Public License Version (“LGPL”). The GPL and LGPL licensed code in this

product is distributed without any warranty. Copies of these licenses are included in this product.

You may obtain the complete corresponding source code (as dened in the GPL) for the GPL Software,

and/or the complete corresponding source code of the LGPL Software (with the complete machine-

readable “work that uses the Library”) for a period of three years after our last shipment of the product

including the GPL Software and/or LGPL Software, which will be no earlier than December 1, 2011, either

(1) for free by downloading it from http://support.asus.com/download;

(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location

where you want to have it shipped to, by sending a request to:

ASUSTeK Computer Inc.

Legal Compliance Dept.

15 Li Te Rd.,

Beitou, Taipei 112

Taiwan

In your request please provide the name, model number and version, as stated in the About Box of the

product for which you wish to obtain the corresponding source code and your contact details so that we

can coordinate the terms and cost of shipment with you.

The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as

the corresponding binary/object code.

This offer is valid to anyone in receipt of this information.

ASUSTeK is eager to duly provide complete source code as required under various Free Open Source

Software licenses. If however you encounter any problems in obtaining the full corresponding source code

we would be much obliged if you give us a notication to the email address gpl@asus.com, stating the

product and describing the problem (please do NOT send large attachments such as source code archives

etc to this email address).

iii

Contents

Safety information ..................................................................................................... vii

About this guide ....................................................................................................... viii

Chapter 1: Product introduction

1.1 Welcome! .................................................................................................... 1-1

1.2 Package contents

....................................................................................... 1-1

1.3 Special features

.......................................................................................... 1-2

1.3.1 Product highlights

........................................................................ 1-2

1.3.2

Dual Intelligent Processors 3 with SMART DIGI+ Power Control 1-4

1.3.3 ASUS Exclusive Features ...........................................................

1-5

1.3.4 ASUS Quiet Thermal Solution .....................................................

1-7

1.3.5 ASUS EZ DIY ..............................................................................

1-7

1.3.6 Other special features .................................................................

1-8

Chapter 2: Hardware information

2.1 Before you proceed ...................................................................................2-1

2.2 Motherboard overview ...............................................................................

2-2

2.2.1 Motherboard layout .....................................................................

2-2

2.2.2 Central Processing Unit (CPU) ...................................................

2-4

2.2.3 System memory ..........................................................................

2-5

2.2.4 Expansion slots .........................................................................

2-13

2.2.5 Onboard switches .....................................................................

2-15

2.2.6 Onboard LEDs ..........................................................................

2-18

2.2.7 Jumper ......................................................................................

2-21

2.2.8 Internal connectors

.................................................................... 2-23

2.3 Building your computer system .............................................................

2-33

2.3.1 Additional tools and components to build a PC system ............

2-33

2.3.2 CPU installation

......................................................................... 2-34

2.3.3 CPU heatsink and fan assembly installation .............................

2-36

2.3.4 DIMM installation

....................................................................... 2-38

2.3.5

Motherboard installation ............................................................ 2-39

2.3.6

ATX Power connection .............................................................. 2-41

2.3.7

SATA device connection ............................................................ 2-42

2.3.8 Front I/O Connector ..................................................................

2-43

2.3.9 Expension Card installation

....................................................... 2-44

2.3.10 USB BIOS Flashback ...............................................................

2-45

2.3.11 Rear panel connection ..............................................................

2-46

2.3.12 Audio I/O connections ...............................................................

2-49

2.4 Startingupforthersttime ....................................................................

2-51

Produkspesifikasjoner

Merke:	Asus
Kategori:	Hovedkort
Modell:	P8Z77-V PRO/THUNDERBOLT
Bredde:	305 mm
Dybde:	244 mm
Strømkildetype:	ATX
Antall HDMI-porter:	1
Hodetelefonutganger:	5
Lydbrikke:	Realtek ALC892
Antall Thunderbolt-porter:	1
Komponent for:	PC
LAN-kontroller:	Intel® 82579V
Støttede minnetyper:	DDR3-SDRAM
Hovedkort formfaktor:	ATX
Antall minnespor:	4
BIOS-type:	UEFI AMI
ACPI-versjon:	2.0a
USB 2.0-tilkoblinger:	5
Antall DVI-D-porter:	1
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
prosessorprodusent:	Intel
Antall PS/2-porter:	1
TPM-tilkobling:	Ja
Minnekanaler:	Tokanals
Ubufret minne:	Ja
Kompatible prosessorserier:	Intel Celeron, Intel Pentium
Prosessorstøpsel:	LGA 1155 (Socket H2)
Støttede lagringsgrensesnitt:	SATA II, SATA III
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Gigabit Ethernet
Antall SATA II-tilkoblinger:	4
Antall SATA III-tilkoblinger:	4
BIOS minnestørrelse:	64 Mbit
Støttede minneklokkehastigheter:	1333,1600,1800,1866,2000,2133,2200,2400,2600 MHz
Systemkort kretsoppsett:	Intel Z77
Minnesportype:	DIMM
Hovedkort-chipsettfamilie:	Intel
Lyd-utgang kanaler:	7.1 kanaler
On-board grafikkort:	Nei
Antall COM-tilkoblinger:	1
Antall understellsviftetilkoblinger:	3
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	4
CPU viftetilkobling:	Ja
S/PDIF-utport:	Ja
Lydtilkobling på fremsiden:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-kontakter:	1
Clear CMOS-pinner:	Ja
Støtter parallellprosesseringsteknologi:	3-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX, Quad-GPU SLI
S/PDIF ut-tilkobling:	Ja
EPS strømtilkobling (8-pin):	Ja
Antall EATX-strømtilkoblinger:	1
