VESA Display Mounting OptionsBase Dimensions

No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd.

Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. Published: 04.08.11 ©

General Features

Display Compatibility:

Visidec Freestanding Double Horizontal is compatible with Flat Panel Displays

measuring up to 635mm (25”) wide, with either 75mm x 75mm or

or 100mm x 100mm VESA mounting hole patterns.

Display Weight Compatibility:

Each Quickshift Donut supports a maximum weight of 12kg (26.5lbs)

Cable Management:

Cable Slot, Cable Clips and Cable Balls (included in package)

Colour Options:

- Pole available in Matt Silver Anodised only

- Quickshift Donut available in Black only

- Base available in Black/Silver only

Warranty:

10 years limited

475mm

(18.70”)

682mm (27”)

Max Height

449mm (17.68”)

Vertical height adjustment

Horizontal adjustment

360°Portrait/Landscape adjustment

±20° Pan/Tilt adjustment

42mm

(1.65”)

42mm

(1.65”)

422mm

(16.61”)

visidec

Technical Specifications

Freestanding | Double Horizontal

305mm

(12”)

302mm

(12”)

89mm

(3.5”)

305mm

12”

Max. width 635mm (25”)

222mm

(8.75”)

422mm

(16.61”)

75mm

100mm

75mm

100mm

VFS-DH

Note: This product supports displays with a

total maximum width (from edge to edge)

of up to 635mm (25”).

Produkspesifikasjoner

Merke:	Atdec
Kategori:	Flatpanelstøtte
Modell:	VFS-DH/TAA
Pakkevekt:	5800 g
Sertifisering:	TAA
Rotasjonsvinkel:	360 °
Skjermstørrelsekompabilitet:	24 "
Av/på-bryter:	Nei
Montasjetype:	Bord
Maksimalvekt (kapasitet):	12 kg
Fjerndrevet:	Nei
Pakningsstørrelse (BxDxH):	530 x 340 x 110 mm
