Side 1/8
D
ual 10 nder Seat Subwoofer Enclosure U
F GM Chevrolet Crew Cab Trucksor
2014-2018 Sierra / Silverado 1500
2014-2019 Sierra / Silverado 2500 / 3500
INSTALLATION GUIDE
NOTE! Read this installation guide thoroughly before disassembling or modifying the
vehicle. Installation of this product requires technical skill, experience and specialized
tools. If in doubt, it’s recommended to have it professionally installed by an authorized
TXGM14D10
A video installation guide is available at:
2
INSTALLATION NOTES
INCLUDED HARDWARE
RECOMMENDED TOOLS
M6 FLANGED HEX HEAD BOLT (4)
75mm / 2.95in Length
ENCLOSURE MOUNTING BRACKETS (2) QUICK-PLUG SPEAKER CONNECTOR (1)
Ratchet
18mm Socket
10mm Socket
Wire Strippers
Optional:
Wire Crimper
Solder/Solder Gun
The TXGM14D10 is designed to mount under the rear seat of GM Crew Cab Trucks.
Some installation steps are more easily completed with a second person.
Speaker wire is required.
Final enclosure impedance: 2ohms.
Recommended amplifier rating: 400-1, 00 watts @ 2ohms.2
1 2
3
D = Driver P = Passenger
3
INSTALLATION
Step 2
Step 1
Lift up the Rear seat to expose the left
and right seat mounting bolts.
Use a 18mm socket to loosen the hex
bolts enough to allow the brackets to
slide under the seat brackets.
Attach the Driver and Passenger Enclosure
mounting brackets to the back of the
enclosure with the 4 supplied M6 Flanged
Hex Bolts.
M6 Bolts
M6 Bolts
Seat
Bolts
Seat
Bolts
