Elettromedia
62018 Potenza Picena (MC) Italy
T +39 0733 870 870 - F +39 0733 870 880
www.elettromedia.it
www.audison.eu
USS4
ACCESSORY
Universal Speakers Simulator
All specications subject to change without notice_17.A
Technical Specications
Input/Output Channels 4
Input Power Max 50 W
Input Impedance 12 Ω
Output Impedance 12 Ω
Remote Out
(only with 12 VDC Power Supply) 12 VDC 150 mA
Remote Out Delayed
(only with 12 VDC Power Supply) 12 VDC 150 mA; 1 to 8 sec.
Weight (gr / lb.) 90 / 0.19
Some OEM sources/head-units have a test circuit that monitors
the presence of a low-impedance load to enable audio outputs.
When you connect this type of head-unit to the high-level inputs
of an Audison bit processor, which has a high impedance load,
audio outputs are silenced. By inserting the USS4 between
the source and the processor / amplier, these problems are
denitively solved. If there is a need to generate a remote signal
to control the amplier turn on/off, it is necessary to power*
the USS4, providing the additional feature of the possibility to
delay the signal from 1 to 8 seconds avoid annoying , so as to
“bumps” upon ignition.
* In countries where the legislation on electromagnetic
compatibility is not mandatory under ECE / UN
Regulation no. 10/5
Speaker interface without power supply
INPUTS
OUTPUTS
PUSH TO OPEN
124mm / 4.88 in.
44mm / 1.73 in.
34mm / 1.34 in.
