128.828 User Manual UK
4K HDMI Splitter 8 1x
Item ref: 128.828 UK
User Manual
4K HDMI splitter to connect a single HDMI source to up to eight displays at the same time. Use with HDMI
cables of a combined 25m per output for HD resolution, or a combined 16m per output for 4K resolution,
without signal loss.
• Simple connection and installation
• Gold plated HDMI connectors for optimum signal transfer
• Supports HDMI v1.4b resolutions up to 3840 x 2160 @ 30Hz
• Supports DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD audio formats
• Ideal for entertainment, hospitality and other commercial venues requiring multiple display feeds from a
single HDMI source
• UK power adaptor supplied
Technical specifications and features
HDMI Version
1.4b
Video Resolution
Up to 3840 x 2160 @ 30Hz
Display Colours
8/10/12bit deep colour
Audio Format
DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD
Max. Bandwidth
340 MHz
Max. Baud Rate
3.4Gbps
Transmission Distance
25m max HD or 16m max 4K (15m input/10m output @ 1080p and 8m
input/output @ 4K)
Dimensions
276 x 136 x 24mm
Weight
660g
Front view
Back view
128.828 User Manual UK
Connection instructions
• Connect the output of the source device to the input of the splitter. Use an HDMI cable of up to 10m for
HD signal or 8m for 4K signal. (NB: to maintain 4K resolution, always use 4K certified cables)
• Connect the outputs of the splitter to the inputs of the display devices. Use HDMI cables of up to 15m per
output for HD signal or 8m per output for 4K signal. (NB: to maintain 4K resolution, always use 4K
certified cables)
• Conn the 5V power adaptor (supplied) to the splitter; plug into a mains outlet and switch on. ect
• Green LEDs on rear of the splitter will illuminate when the source and display devices are connected and
switched on.
In the b ox
1. HDMI Splitter 1x8
2. 5V DC Power Adaptor
3. User Manual
Warning
• For reasons of electrical safety, this device must never be immersed in water, exposed to damp conditions
or excessive force.
• Do not use this device if you find that it is damaged in any way.
• Only use the power supply provided b the manufacturer. y
• When not in use for long periods, disconnect the power supply from the mains.
• Do not attempt to repair this device or take apart under any circumstances, as this will invalidate your
warranty.
This product is classed as Electrical or Electronic equipment an hould not be disposed with other household or commercial waste at d s
the end of its useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
Copyright© 21 AVSL Group Ltd Unit 2 Bridgewater Park, AVSL (Europe) , Unit 3D North Point House, 20 , Ltd
Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
