Side 1/6
433.92 MHZ
CR2032
IP20
UNIVERSAL TRANSMITTER UNDER THE
SWITCH
WS360
WS360
WIRELESS
TRANSMITTER
Designed and manufactured in CZ.
EU DECLARATION OF CONFORMITY
Here is ELEKTROBOCK CZ s.r.o. declares that the WS360
radio equipment complies with Directive 2014/53 / EU. The
full text of the EU Declaration of Conformity is available at
the following Internet address: www.elbock.cz
150m
Description
WS360 serves as a transmitter for wireless bells of the BZ90x
series as well as for remote control of WS3xx receivers, which
can switch various el. appliances (lighting, blinds, electric
locks, direct heaters, etc.).
The transmitter contains 4 inputs (K1 to K4). When any
channel is pressed, a coded signal is sent to the learned
receiver that performs the function.
Each channel can have a dierent function and control several
receivers at once.
Signal transmission is indicated by a red indicator diode.
Notice
Do not place the transmitter near power cables and large
metal objects! It must not be mounted on metal substrates!
Designed for indoor use! In case of improper placement, the
reach of the whole set will be signicantly reduced!
Construction
The transmitter is designed for installation in the KU / KP68
installation box.
a) Remove the rear cover of the transmitter,
b) remove the battery cover paper,
c) reinstall the back cover,
d) connect the transmitter according to the wiring diagram,
e) pair with the receiver.
K1
K2
K3
K4
COM
WS360
TL
Diagram of connection:
