Installation

and Operation

411298001

FRITZ!Powerline

500E

Inst

alla

tion

and O

eratio

Table of Contents

Symbols and Highlighting . . . . . . . . . . . . . . . . . . . . . . . . 4

1 FRITZ!Powerline 500E . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 Before You Connect the FRITZ!Powerline . . . . . . . . . . . . . 6

2.1 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.2 Security Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.3 LEDs, Buttons and Network Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3 Connecting the FRITZ!Powerline. . . . . . . . . . . . . . . . . . . . 9

3.1 Connecting FRITZ!Powerline 500E Set . . . . . . . . . . . . . . . . . . . . . . . . 9

3.2 Expanding a FRITZ!Powerline Network . . . . . . . . . . . . . . . . . . . . . . . 10

3.3 Connecting Powerline Adapters from Other Manufacturers . . . . . . 11

3.4 Connecting Multiple Network Devices . . . . . . . . . . . . . . . . . . . . . . . 11

4 Security in the Powerline Network . . . . . . . . . . . . . . . . . 12

4.1 Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.2 Changing the Network Password . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

5 Application Examples. . . . . . . . . . . . . . . . . . . . . . . . . . . 16

5.1 Internet Connection for All Network Devices . . . . . . . . . . . . . . . . . . 16

5.2 Networking Computers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

5.3 Game Consoles on the Internet Connection or in the Home Network

5.4 TVs and Stereo Systems in the Network . . . . . . . . . . . . . . . . . . . . . . 19

FRITZ!Powerline 500E-e.fm Seite 2 Dienstag, 28. August 2012 6:41 18

. . 18

6 The AVM FRITZ!Powerline Program. . . . . . . . . . . . . . . . . 20

7 Factory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

8 Power-saving Features of FRITZ!Powerline 500E. . . . . . 23

9 Optimizing Transmission Capacity. . . . . . . . . . . . . . . . . 24

10 FAQs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

10.1 Multiple Powerline Networks in Once Circuit . . . . . . . . . . . . . . . . . . 25

10.2 FRITZ!Powerline across Various Phases in the Power Supply . . . . . 25

10.3 Electricity Meter, Fuse Box, GFCI Ground Fault Circuit Interrupter . 26

10.4 Adapters from Other Manufacturers in the Powerline Network . . . 26

10.5 Kinds of Devices on the Powerline Adapter . . . . . . . . . . . . . . . . . . . 27

11 Powerline: Technical Background . . . . . . . . . . . . . . . . . 28

12 Electromagnetic Interference . . . . . . . . . . . . . . . . . . . . . 29

13 Comparison with other Network Technologies . . . . . . . 30

14 Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . 32

15 Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

15.1 Information in the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

15.2 Support from the Support Team . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

15.3 Manufacturer’s Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Legal Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Legal Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Declaration of CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Disposal Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

FRITZ!Powerline 500E-e.fm Seite 3 Dienstag, 28. August 2012 6:41 18

Produkspesifikasjoner

Merke:	AVM
Kategori:	strømlinjeadapter
Modell:	Fritz! Powerline 500E
Vekt:	170 g
Bredde:	61 mm
Dybde:	72 mm
Høyde:	92 mm
LED-indikatorer:	Ja
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Antall per pakke:	- stykker
Maksimal dataoverføringshastighet:	500 Mbit/s
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	1 W
Produktfarge:	Red, White
Kabler inkludert:	LAN (RJ-45)
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	128-bit AES
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Gigabit Ethernet
Videoopptaksgrensesnitt:	Ethernet
Intern:	Nei
Ethernet LAN-grensesnittype:	Gigabit Ethernet
