Bauknecht GSI 4033 BR Bruksanvisning
Bauknecht
Oppvaskmaskin
GSI 4033 BR
Les nedenfor 📖 manual på norsk for Bauknecht GSI 4033 BR (10 sider) i kategorien Oppvaskmaskin. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/10
12
GB SUMMARY
BEFORE USING THE DISHWASHER
PAGE
13
PROTECTING THE ENVIRONMENT
PAGE
13
PRECAUTIONS AND GENERAL RECOMMENDATIONS
PAGE
13
ENERGY AND WATER SAVING TIPS
PAGE
13
HOW TO FILL THE SALT CONTAINER
PAGE
14
HOW TO FILL THE RINSE AID DISPENSER
PAGE
15
HOW TO FILL THE DETERGENT DISPENSER
PAGE
16
HOW TO USE THE DISHWASHER
PAGE
17
CONNECTIONS
PAGE
18
MAINTENANCE AND CLEANING
PAGE
20
TROUBLESHOOTING GUIDE
PAGE
21
AFTER-SALES SERVICE
PAGE
21
For maximum satisfaction from your dishwasher, carefully read these user
instructions and consult the wash programme chart.
94017-gb.fm5 Page 12 Wednesday, September 26, 2001 6:15 PM
13
•After unpacking, make sure the appliance is
undamaged and that the door closes
correctly. Do not use the appliance if it is
damaged. If in doubt, consult your local
retailer.
•Keep potentially hazardous packaging
(plastic bags etc.) out of the reach of children.
•This appliance is designed for use in the home
in compliance with its intended purpose.
•All water and electrical connections must be
carried out by a qualified technician in
compliance with the manufacturer's
instructions (refer to the enclosed installation
booklet) and current local safety regulations.
3. Packing
The packing box may be fully recycled as
confirmed by the recycling symbol .
4. Appliance
The appliance is built from reusable
materials.
If you decide to scrap the dishwasher, it
must be disposed of in compliance with local
waste disposal laws. Before scrapping, cut
off the power cable so that the appliance
cannot be connected to the mains.
Child safety
•Do not allow children to play with the
dishwasher.
•Store the detergent, rinse aid and salt in a dry
place out of the reach of children.
General recommendations
•Only use detergents, rinse aids and
regeneration salts specially recommended
for use in domestic dishwashers.
•On completion of the wash programme
switch o the dishwasher and turn o the
water tap.
•Before cleaning or carrying out maintenance,
switch off the appliance, disconnect the
mains plug and turn off the water tap.
•If a fault occurs, switch off the appliance and
turn off the water tap.
•The open dishwasher door can only support
the weight of the loaded rack when pull out.
Do not rest objects on the open door or sit or
stand on it since the appliance may topple
over.
•If necessary, the power cable may be
replaced with one the same obtained from
our After-Sales Service. The power cable
must only be replaced by a qualified
technician.
•For appliances with water-stop system:
The water inlet hose and plastic casing
contain electrical components. Do not
therefore cut the hose or immerse the plastic
casing in water. If the hose is damaged
switch off the appliance immediately.
•Do not use solvents inside the dishwasher:
risk of explosion!
•Load capacity: 12 place settings
.
EC Declaration of Conformity
This appliance has been designed,
constructed and distributed in compliance
with the safety requirements of EC
Directives:
•73/23/EC
•89/336/EC
•93/68/EC
•Do not rinse crockery under running water.
•Always fully load the dishwasher before
switching on or set the wash programme to
half load (if available) if one rack only is
loaded.
•If ecological energy sources are available
such as solar panel heating, heat pumps or
centralised heating systems, the appliance
may be connected to the hot water mains up
to a maximum temperature of 60°C.
Make sure the water inlet hose is of the
correct type. Refer to the “Connections”
chapter in these user instructions.
BEFORE USING THE DISHWASHER
PROTECTING THE ENVIRONMENT
PRECAUTIONS AND GENERAL RECOMMENDATIONS
ENERGY AND WATER SAVING TIPS
94017-gb.fm5 Page 13 Wednesday, September 26, 2001 6:15 PM
14
Check the water hardness level in your
area.
Consult your local Water Board or check
your last water bill.
•Set the water hardness by turning the
selector (if fitted) inside the door (top left)
with a screwdriver. Use the table below to
set the dial to the required setting.
If the water hardness level falls within category 1
(soft), no salt is required.
•If the water hardness level exceeds
category 1-2 (medium), before using the
dishwasher for the first time, fill the salt
container and run a wash cycle so that
any excess saline solution discharged is
immediately removed by the water to
prevent corrosion. The pre-rinse cycle is
not sufficient for this purpose.
•Check the salt level regularly.
•Important: Only use regeneration salts
recommended for use in domestic
dishwashers.
Do not fill the salt container with
detergent as this will cause irreparable
damage to the water softener system.
To fill the salt container:
1.
Remove the lower rack.
2.
Unscrew the cap by turning it counter-
clockwise.
3.
If the dishwasher is new, ll the salt container
to the rim with water.
4.
Fill the container to the rim with salt
(max. 2 kg) and stir with a spoon handle.
5.
Screw the cap back on by turning it
clockwise.
Salt level indicator
The dishwasher is equipped with an electric or
visual salt level indicator depending on the
model installed.
Electric indicator:
The salt level indicator lamp on the control
panel illuminates when the salt container is
empty.
Visual indicator:
The red oat is clearly visible in the cap window
when the salt container is full. The red float
lowers and is no longer visible when the salt
container is empty.
HOW TO FILL THE SALT CONTAINER
Selector
setting
Water
hardness
German
degrees °dH
French
degrees °fH
0 1 soft 0 - 5 0 - 9
1 1 - 2 medium 6 - 10 10 - 18
2 2 medium 11 - 15 19 - 27
3 3 medium-hard 16 - 21 28 - 37
4 4 hard 22 - 28 38 - 50
5 4 very hard 29 - 35 51 - 63
6
4 extremely
hard
36 - 60 64 - 107
94017-gb.fm5 Page 14 Wednesday, September 26, 2001 6:15 PM
