Side 1/4
5019 496 90113
GB
GSU 4956
Quick Reference Guide
Before using the dishwasher, read the user instructions!
BK/I/K/GB
(We reserve the right to make technical modifications)
Add rinse aid
Add regeneration salt
Only add regeneration salt
immediately before starting a
wash programme.
“Half Load” button
This function can be used with any
programme. The indicator lamp switches
on. The wash cycle is activated for the
upper
or
lower rack
only
.
“Delayed start” button
The wash cycle can be programmed to start
after 3-6-9 hours.
Then press the Start button.
The wash programme will start at the set
time.
1) Reference programme for energy label in
compliance with EN 50242 regulations;
2) Refer to “User instructions“;
3) Values may vary in relation to usage, e.g.:
dierent loads, water temperatures - above or
below 15° C - as well as water hardness and
power supply voltage, etc.
Programme selector knob
Start button
Switches “on” when the
dishwasher is operating. Flashes
when a fault occurs. Switches off
at the end of the programme.
Indicators
Wash cycle
Pre-wash Washing Drying
Programme
end
Options
Programme chart
Detergent
2)
Consumption
3)
Programmes Loading instructions A B Litres kWh Minutes
AutoNormal
40-55°C
Recommended programme for routine
washes, for crockery with little dried-on
food.
X X 10-13 0.8-1.05 50-110
AutoIntensive
60-70°C
Recommended programme for heavily
soiled crockery, especially suitable for
pans and saucepans.
X X 13-20 1.1-2.0 90-140
Pre-Rinse cold
Crockery to be washed later. - - 4.0 0.03 14
Glass 40°C
Light soiling, for example glasses
and cups.
X - 10.0 0.80 55
Rapid 30 min 40°C
Lightly soiled crockery with no
dried-on food.
X - 10.0 0.65 30
Eco
1)
50°C
Normally or heavily soiled crockery. X X 13.0 1.24 128
BK/II/K/GB
How to use the appliance
Further indications are given in the single chapters and in the user instructions.
Automatic start by turning the programme selector knob (in
case of retractable knob, first press the knob to access it).
Large compartment
A:
With each wash cycle.
Small compartment
B:
For programmes with pre-wash only.
Mechanical indicator lamp
C
.
Electric indicator on control panel (if provided).
On models with water softener system only.
Mechanical indicator lamp
D
.
Electric indicator on control panel (if provided).
Refer to the dishwasher loading instructions.
Select the desired programme.
The corresponding indicator lamp comes on.
If necessary (and if provided) the corresponding indicator
lamp lights up.
The selected programme
is then memorised (even
in the event of power
failure).
- Only open the dishwasher if necessary
(Warning: beware of hot steam).
- If the appliance is switched off during
a wash cycle, when switched on
again it will resume the cycle from
where it was interrupted.
Only after the START button has switched off: access the knob
(in case of retractable knob, press and then release the knob).
Warning: when the door is opened steam comes out!
Unload the appliance, starting from the lower rack.
Switch on the appliance
How to fill the
detergent dispenser
C
BA
Check the
rinse aid level
Check the regeneration
salt level
Load the racks
Close the door,
turn on the water tap
Select a programme
Select additional
options
Press the START button
“Change programme”
Press the START button for 2 sec. until
the Start indicator lamp switches off;
Select another programme and
press the START button again.
Wash cycle
Switch off the appliance
Shut off the water tap,
unload the racks
BK/III/GB
Dishwasher loading instructions and racks provided
Upper rack:
depending on the model
Multi-purpose support (A)
1)
:
Depending on the position, for
long-handles utensils, cups and
glasses. May be used in three
different positions.
Crockery holders (B):
Depending on the position, for
example plates, cups and long-
stemmed glasses.
Revolving glass support (C)
2)
:
Depending on the position, for
example small or long-
stemmed glasses.
Half Load:
Load
the upper rack
only
.
Place the cutlery basket (
D
) in
the upper rack.
Rack height adjustment
(also when loaded):
•
Lower adjustment:
pull out
the
two
rack handles
outwards (
E
) and lower the
rack.
•
Upper adjustment:
pull the
two
handles (
E
) upwards until
the rack clicks into place
(Factory setting).
The rack must be level on
both sides.
Lower rack:
Depending on the model with
fixed or tilting plate holders (
F
).
Half Load:
Load the lower rack
only
.
Greater washing power,
particularly for plates and
saucepans.
Cutlery basket (G) or (H):
Some models are provided
with a grid (
I
) that can be
fitted onto the cutlery basket
to keep items separated.
Cutlery basket (
D
) for
appliances with half load only.
Do not use the appliance for items not suitable for washing in a dishwasher, for example wooden
items, aluminium, plastic utensils, tin, hand-decorated crockery (unglazed), silver cutlery.
Spare parts which are sold separately:
1)
Multi-purpose support (A) - N. AMH 369.
2)
Revolving glass support (C) - N. WGH 1000.
