K:\Webshop\neue-struktur\T-Produktbeschreibung\60\Originale_Englisch_PA04\2255114_01013.doc Erstelldatum 17.12.2003 18:21
aktualisiert: 08.01.2004
Electric Hoist
Art.-No.: 22.551.14
SHZ 125/250 Bavaria
Bar-Code: 4006825221237
with 18 m cable
Sales Unit: 2 pcs
The Einhell electric hoist is conform to the latest state of art based on the valid norms and legal standards of 1999. Due
to the adaptation to the latest standards, several advantages should be noted:
-
The start button is equipped with an . This device guarantees a safe cut-off in case emergency-cut-off button
of failure of the start switch.
-
The start button is designed in (safety insulated). insulation class II
-
A assures that the hoist will safely be cut-off at the upper end (i. e. in case the 2 forcibly actuated end switch
contacts stick together).
-
Improved brake: In case of a defect on the pressure spring (i. e. rupture of the wire) stopping of the load still
is assured.
-
The brake will be activated in case of power failure in the motor.
-
The warrants a longer service life of the drive unit.improved gear
-
The reduces twisting of the loads during the lifting motion. non-rotating steel rope
-
The load hook with : This added latch prevents an unintended loosening of the load additional safety latch
suspension device.
-
The prevents it from overheating. motor with overload protection
Supplied with: Technical data:
-
Fastening with 2 double clamps Payload: 125 kg without pulley
-
Start button with emergency button 250 kg with pulley
-
Deflection pulley with payload hook Lifting height: 17,5 m without pulley
-
18 m non-rotating (kinking) steel wire Ø 3,05 mm 8,7 m with pulley
-
Motor with thermal cut-out Mains: 230 V~ 50 Hz
-
An automatic brake secures the load Power: 500 watts S3 20 %
in any position Rope speed: without pulley: 10 m/min.
with pulley: 5 m/min.
Weight: 11,4 kg
Packing dimensions: 350 x 220 x 140 mm
Hoist level arm Art.-No.: 22.553.96
Global SA 1200 Bar-Code: 4006825 221244
Emergency button
Safety latch
As accessory available:
