U-CONTROL UMX49/UMX61

Version 1.1 August 2006

User’s Manual

U-CONTROL UMX49/UMX61

This symbol, wherever it appears, alerts you to the

presence of uninsulated dangerous voltage inside

the enclosure—voltage that may be sufficient to

constitute a risk of shock.

This symbol, wherever it appears, alerts you to

important operating and maintenance instructions

in the accompanying literature. Please read the

manual.

IMPORTANT SAFETY PRECAUTIONS

CAUTION: To reduce the risk of electric shock, do not remove

the cover (or back). No user-serviceable parts

inside; refer servicing to qualified personnel. Only

qualified personnel may perform repairs.

WARNING: The apparatus shall not be exposed to dripping or

splashing and no objects filled with liquids, such

as vases, shall be placed on the apparatus.

DETAILED SAFETY INSTRUCTIONS:

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with a dry cloth.

7) Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding-type plug has

two blades and a third grounding prong. The wide blade

or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an

electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from

tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged

in any way, such as power supply cord or plug is damaged,

liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

15) CAUTION - These service instructions are for use by

qualified service personnel only. To reduce the risk of electric

shock do not perform any servicing other than that contained

in the operation instructions unless you are qualified to do

so.

U-CONTROL UMX49/UMX61

TABLE OF CONTENTS

1. INTRODUCTION ......................................................... 4

1.1 Before you get started ................................................... 4

1.1.1 Shipment ............................................................... 4

1.1.2 Initial operation and power supply....................... 4

1.1.3 Online registration ................................................ 4

1.2 System requirements...................................................... 5

2. INTRODUCTION TO MIDI ............................................5

2.1 MIDI control for beginners .............................................. 5

2.2 USB mode and stand-alone operation ........................... 6

2.2.1 USB mode ............................................................. 6

2.2.2 Stand-alone operation .......................................... 6

3. CONTROL ELEMENTS AND CONNECTIONS .............6

4. OPERATION ...............................................................7

4.1 PLAY mode ..................................................................... 7

4.1.1 The FACTORY MEMORY...................................... 7

4.1.2 The USER MEMORY ............................................. 7

4.2 ASSIGN mode ................................................................. 8

4.2.1 Setting the GLOBAL CHANNEL ........................... 8

4.2.2 Individual channel assignment ............................. 8

4.2.3 GLOBAL CHANNEL assignment .......................... 8

4.2.4 The PANIC key combination ................................. 8

4.2.5 The SNAPSHOT SEND command ......................... 8

4.2.6 LOCAL OFF .......................................................... 8

4.2.7 Control elements assignment ............................... 9

4.2.8 Program and bank change ................................... 9

4.2.9 Other functions of the OCTAVE SHIFT buttons . 10

4.2.10Velocity Sensitivity ............................................. 11

4.2.11The FACTORY RESET command ....................... 11

5. SPECIFICATIONS .....................................................12

6. APPENDIX ................................................................13

7. WARRANTY ..............................................................14

Dear Customer,

Welcome to the team

of BEHRINGER users,

and thank you very

much for expressing

your confidence in us

by purchasing the

U-CONTROL.

Writing this foreword

for you gives me great

pleasure, because it

represents the culmination

of many months of

hard work delivered

by our engineering

team to achieve a very

ambitious goal. With

the U-CONTROL we

present you our first

keyboard which, thanks

to its flexibility, can be used on stage as a master keyboard

controller as well as a pure MIDI controller. The task of designing

our new U-CONTROL certainly meant a great deal of

responsibility, which we assumed by focusing on you, the

discerning user and musician. Meeting your expectations

also meant a lot of work and night shifts. But it was fun, too.

Developing a product usually brings a lot of people together,

and what a great feeling it is when all who participated in

such a project can be proud of what they’ve achieved.

It is our philosophy to share our enjoyment with you, because

you are the most important member of the BEHRINGER team.

With your highly competent suggestions for new products you’ve

made a significant contribution to shaping our company and making

it successful. In return, we guarantee you uncompromising quality

as well as excellent technical and audio properties at an extremely

reasonable price. All of this will enable you to give free rein to

your creativity without being hampered by budget constraints.

We are often asked how we manage to produce such high-

quality devices at such unbelievably low prices. The answer is

quite simple: it’s you, our customers! Many satisfied customers

mean large sales volumes enabling us to get better purchasing

terms for components, etc. Isn’t it only fair to pass this benefit on

to you? Because we know that your success is our success

too!

I would like to thank all of you who have made the U-CONTROL

possible. You have all made your own personal contributions,

from the developers and many other employees at this company,

to you, the BEHRINGER user.

My friends, it’s been worth the effort!

Thank you very much,

Uli Behringer

FOREWORD
