Berker 80162770 Bruksanvisning

Berker Bryter 80162770

Les nedenfor 📖 manual på norsk for Berker 80162770 (4 sider) i kategorien Bryter. Denne guiden var nyttig for 21 personer og ble vurdert med 4.2 stjerner i gjennomsnitt av 11 brukere

Last ned PDF

Side 1/4

80162770

Push-button 2gang, + RGB LED, internal temp. sensor, KNX - K.1, p. white

Technical characteristics

Architecture

Fixing mode flush-mounting

Functions

With room temperature controller Yes

Easy link functions

operating concept "independent push-button"

function predefined, operating concept for "roller

shutter/blind" function predefined, switching of

scenes (1..8) possible, Orientation LED can be

controlled via object, brightness value of the status

LED for day/nighttime operation preset, status LED

for day/nighttime operation can be controlled via

object, integrated temperature sensor with output of

the measured values, Colour of status LED uniformly

adjustable for complete device, push-button

functions: including switching, dimming, roller

shutter/blind, timer, priority, temperature setpoint

adjustment, operating mode changeover

Function

Function for manual interruption of automatic

functions already triggered

Function

operating surfaces as buttons (single-surface

operation) and rockers (two-surface operation), the

brightness of status LEDs are individually adjustable

for button/ rocker function, brightness value of the

status LEDs for day/nighttime operation adjustable

via object or manually, value transmitter for

dimming, position, brightness temperature values 1

and 2 byte, button/rocker functions for switching,

dimming, roller shutter/blind, value transmitter 1/2

byte, room thermostat extension unit, priority,

scene, automatic control deactivation, integrated

temperature sensor with output of the measured

values via object, button functions for switching,

dimming, roller shutter/blind, timer, value

transmitter 1/2 byte, room thermostat extension

unit, priority, scene, 2-channel mode, step switch,

automatic control deactivation, rocker functions for

switching, dimming, roller shutter/blind, value

transmitter 1/2 byte, room thermostat extension

unit, priority, scene, 2-channel mode, automatic

control deactivation, 3-step switch, function for

incremental selection of up to 7 stored values,

Status LED configurable in its colour per button,

parameter defineable lock function

Controls and indicators

With LED indication Yes

Number of buttons 2

Operation

operating areas configurable as one or two-area

operation

Electric current

Bus current consumption (data transfer) max. 20 mA

Dimensions

Subject to technical modifications

Produkspesifikasjoner

Merke:	Berker
Kategori:	Bryter
Modell:	80162770
Utgangseffekt:	150 mW
Temperaturmåleområde:	-5 - 45 °C
Sensortype:	Temperatursensor
Modell/Type:	Innebygget
Temperature measuring units:	°C
Formål:	Innendørs
