KAMLÅSNINGSSATS
KAMLÅSINGSSETT
NOKKA-AKSELIN LUKITUSSARJA
KNASTAKSEL-LÅSEVÆRKTØJ
Art. 19-1000
2
© 2016-03-01 Biltema Nordic Services AB
VOLVO CAMSHAFT/CRANKSHAFT ALIGNMENT SET
This set is designed to properly secure and align the cylinder head, cam and crankshaft during removal
and installation of cylinder head assemblies on 4, 5, and 6 cylinder engines - also for the proper
installation of camshaft cover to the engine head and useful when replacing camshaft seal.
Applications include
Applicable models: 850, 960, S40, S70 and S90
Applications include 700, 800, 850, 900, 960, C70 Coupe and Conv, S40, S60, S70, S80, S90, V70-2000,
V70XC, XC70, V90, XC90
Models: S80 (07-), V70 (08-), S80 (-06), XC90, V70 (00-08), V70 XC (01-) / XC70 (-07), S60, C30, C70 (06-),
S40 (04-), V50, S40 (-04), V40, 850, C70
Coupe (-02), C70 Conv (-05), S70, V70 (-00), V70 XC (-00), 960, S90, V90
Engine codes: B41XX, B42XX, B52XX, B62XX, B63XX, GB5252S
Specification
2 x Press Tools OEM 999-5454
1 x Angled Plate OEM 999-5453
1 x Cam Holder OEM 999-5452
1 x Timing Pin OEM 999-5451
SE – KAMLÅSNINGSSATS
För Volvos fyra, fem och sexcylindriga motorer med
erventilsteknik. Används för korrekt hopsättning och
injustering av kamaxlar och vevaxel. Innehåller också
verktyg för att få kamaxelkåpan i rätt läge när du har
bytt kamaxeltätningar och packning.
Volvos referensnummer:
999-5451, 999-5452, 999-5453, 2x 999-5454.
SPECIFIKATIONER:
• Modeller:850,960,S40,S70ochS90
• Applikationer:700,800,850,900,960,C70
CoupeochConv,S40,S60,S70,S80,S90,
V70-2000,V70XC,XC70,V90,XC90.
• Modeller/årtal:S80(07-),V70(08-),S80(-06),
XC90,V70(00-08),V70XC(01-)/XC70(-07),
S60,C30,C70(06-),S40(04-),V50,S40(-04),
V40,850,C70
• Coupe(-02),C70Conv(-05),S70,V70(-00),
V70XC(-00),960,S90,V90.
• Motorkoder:B41XX,B42XX,B52XX,B62XX,
B63XX,GB5252S
• PassarävenVolvoPENTAmederventilsteknik.
INNEHÅLL
2xPressverktyg
1 x Vinkelplatta
1 x Kamhållare
1 x Låspinne
Denna bild visar verktygen vid användning.
Denna bild visar verktygen placerade på motorn.
This diagram shows tools 999-5452 and 999-5451 in service use.
This diagram shows the tools 999-5454 and 999-5453 placed on the engine for servicing.
This diagram shows tools 999-5452 and 999-5451 in service use.
This diagram shows the tools 999-5454 and 999-5453 placed on the engine for servicing.
VOLVO CAMSHAFT/CRANKSHAFT ALIGNMENT SET
This set is designed to properly secure and align the cylinder head, cam and crankshaft during removal
and installation of cylinder head assemblies on 4, 5, and 6 cylinder engines - also for the proper
installation of camshaft cover to the engine head and useful when replacing camshaft seal.
Applications include
Applicable models: 850, 960, S40, S70 and S90
Applications include 700, 800, 850, 900, 960, C70 Coupe and Conv, S40, S60, S70, S80, S90, V70-2000,
V70XC, XC70, V90, XC90
Models: S80 (07-), V70 (08-), S80 (-06), XC90, V70 (00-08), V70 XC (01-) / XC70 (-07), S60, C30, C70 (06-),
S40 (04-), V50, S40 (-04), V40, 850, C70
Coupe (-02), C70 Conv (-05), S70, V70 (-00), V70 XC (-00), 960, S90, V90
Engine codes: B41XX, B42XX, B52XX, B62XX, B63XX, GB5252S
Specification
2 x Press Tools OEM 999-5454
1 x Angled Plate OEM 999-5453
1 x Cam Holder OEM 999-5452
1 x Timing Pin OEM 999-5451
NO – KAMLÅSINGSSETT
For Volvo-motorer med erventilteknologi og re, fem
ogsekssylindre.Brukesforkorrektmonteringog
justering av kamaksel og veivaksel. Inneholder også
verktøy for å få kamakselkåpen i riktig stilling når du
harbyttetkamakseltettingogpakning.Spesikasjon:
Volvos referansenummer:
999-5451, 999-5452, 999-5453, 2x 999-5454.
SPESIFIKASJONER:
• Modeller:850,960,S40,S70ogS90
• Bruksområder:700,800,850,900,960,C70
CoupeogConv,S40,S60,S70,S80,S90,V70-
2000,V70XC,XC70,V90,XC90.
• Modell/årstall:S80(07-),V70(08-),S80(-06),
XC90,V70(00-08),V70XC(01-)/XC70(-07),
S60,C30,C70(06-),S40(04-),V50,S40(-04),
V40,850,C70
• Coupe(-02),C70Conv(-05),S70,V70(-00),V70
XC(-00),960,S90,V90.
• Motorkoder:B41XX,B42XX,B52XX,B62XX,
B63XX,GB5252S
• PasserogsåVolvoPENTAmederventilteknologi.
INNHOLD
2xPressverktøy
1 x Vinkelplate
1 x Kamholder
1 x Låsepinne
Dette bildet viser verktøyet i bruk.
Dette bildet viser verktøyet plassert på motoren.
This diagram shows tools 999-5452 and 999-5451 in service use.
This diagram shows the tools 999-5454 and 999-5453 placed on the engine for servicing.
This diagram shows tools 999-5452 and 999-5451 in service use.
This diagram shows the tools 999-5454 and 999-5453 placed on the engine for servicing.
Art. 19-1000
3
© 2016-03-01 Biltema Nordic Services AB
VOLVO CAMSHAFT/CRANKSHAFT ALIGNMENT SET
This set is designed to properly secure and align the cylinder head, cam and crankshaft during removal
and installation of cylinder head assemblies on 4, 5, and 6 cylinder engines - also for the proper
installation of camshaft cover to the engine head and useful when replacing camshaft seal.
Applications include
Applicable models: 850, 960, S40, S70 and S90
Applications include 700, 800, 850, 900, 960, C70 Coupe and Conv, S40, S60, S70, S80, S90, V70-2000,
V70XC, XC70, V90, XC90
Models: S80 (07-), V70 (08-), S80 (-06), XC90, V70 (00-08), V70 XC (01-) / XC70 (-07), S60, C30, C70 (06-),
S40 (04-), V50, S40 (-04), V40, 850, C70
Coupe (-02), C70 Conv (-05), S70, V70 (-00), V70 XC (-00), 960, S90, V90
Engine codes: B41XX, B42XX, B52XX, B62XX, B63XX, GB5252S
Specification
2 x Press Tools OEM 999-5454
1 x Angled Plate OEM 999-5453
1 x Cam Holder OEM 999-5452
1 x Timing Pin OEM 999-5451
FI – NOKKA-AKSELIN LUKITUSSARJA
MoniventtiilitekniikallatoimiviinVolvonneli-,viisi-ja
kuusisylinterisiin moottoreihin. Auttaa kokoamaan
ja säätämään nokka-akselin ja kampiakselin oikein.
Sisältäämyöstyökalutnokka-akselikotelonase-
moimiseksi oikein nokka-akselitiivisteiden ja tiivisteen
vaihtamisen jälkeen. Volvon artikkelinumero:
999-5451, 999-5452, 999-5453, 2x 999-5454.
TEKNISET TIEDOT:
• Mallit:850,960,S40,S70jaS90
• Versiot:700,800,850,900,960,C70Coupe
jaConv,S40,S60,S70,S80,S90,V70-2000,
V70XC,XC70,V90,XC90.
• Mallit/vuosimalli:S80(07-),V70(08-),S80(-06),
XC90,V70(00-08),V70XC(01-)/XC70(-07),
S60,C30,C70(06-),S40(04-),V50,S40(-04),
V40,850,C70
• Coupe(-02),C70Conv(-05),S70,V70(-00),V70
XC(-00),960,S90,V90.
• Moottorikoodit:B41XX,B42XX,B52XX,B62XX,
B63XX,GB5252S
• SopiimyösmoniventtiilitekniikallatoimiviinVolvo
PENTA-moottoreihin.
SISÄLTÖ
2xPuristustyökalu
1 x Kulmalevy
1xNokkapidike
1 x Lukkotappi
Tämäkuvaosoittaatyökalujenkäytön.
Tässäkuvassatyökalutonsijoitettumoottoriin
This diagram shows tools 999-5452 and 999-5451 in service use.
This diagram shows the tools 999-5454 and 999-5453 placed on the engine for servicing.
This diagram shows tools 999-5452 and 999-5451 in service use.
This diagram shows the tools 999-5454 and 999-5453 placed on the engine for servicing.
VOLVO CAMSHAFT/CRANKSHAFT ALIGNMENT SET
This set is designed to properly secure and align the cylinder head, cam and crankshaft during removal
and installation of cylinder head assemblies on 4, 5, and 6 cylinder engines - also for the proper
installation of camshaft cover to the engine head and useful when replacing camshaft seal.
Applications include
Applicable models: 850, 960, S40, S70 and S90
Applications include 700, 800, 850, 900, 960, C70 Coupe and Conv, S40, S60, S70, S80, S90, V70-2000,
V70XC, XC70, V90, XC90
Models: S80 (07-), V70 (08-), S80 (-06), XC90, V70 (00-08), V70 XC (01-) / XC70 (-07), S60, C30, C70 (06-),
S40 (04-), V50, S40 (-04), V40, 850, C70
Coupe (-02), C70 Conv (-05), S70, V70 (-00), V70 XC (-00), 960, S90, V90
Engine codes: B41XX, B42XX, B52XX, B62XX, B63XX, GB5252S
Specification
2 x Press Tools OEM 999-5454
1 x Angled Plate OEM 999-5453
1 x Cam Holder OEM 999-5452
1 x Timing Pin OEM 999-5451
DK – KNASTAKSEL-LÅSEVÆRKTØJ
TilVolvore-,fem-ogsekscylindredemotorermed
erventilteknik.Brugestilkorrektmonteringog
indstilling af knastaksler og krumtapaksel. Indeholder
også værktøj til at få ventildækslet i korrekt position
efter udskiftning af knastakselpakdåser og pakning.
Volvo referencenummer:
999-5451, 999-5452, 999-5453, 2x 999-5454.
SPECIFIKATIONER:
• Modeller:850,960,S40,S70ogS90
• Passertil:700,800,850,900,960,C70Coupe
ogConv.,S40,S60,S70,S80,S90,V70-2000,
V70XC,XC70,V90,XC90.
• Modeller/årgang:S80(07-),V70(08-),S80(-06),
XC90,V70(00-08),V70XC(01-)/XC70(-07),
S60,C30,C70(06-),S40(04-),V50,S40(-04),
V40,850,C70
• Coupe(-02),C70Conv.(-05),S70,V70(-00),V70
XC(-00),960,S90,V90.
• Motorkoder:B41XX,B42XX,B52XX,B62XX,
B63XX,GB5252S
• PasserogsåtilVolvoPENTAmederventilteknik.
INDHOLD
2xPresseværktøj
1 x Vinkelplade
1 x Knastakselholder
1 x Låsestift
Denne g. viser værktøjet i brug.
Denne g. viser værktøjet placeret på motoren.
This diagram shows tools 999-5452 and 999-5451 in service use.
This diagram shows the tools 999-5454 and 999-5453 placed on the engine for servicing.
This diagram shows tools 999-5452 and 999-5451 in service use.
This diagram shows the tools 999-5454 and 999-5453 placed on the engine for servicing.
