Side 1/184

Provides flexible and super-fast crosspoint

switching of Full HD video in KVM enterprises.

ServSwitch

™

DKM FX and DKM FX Compact

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax

724-746-0746฀฀•฀฀Mailing฀address:฀Black฀Box฀Corporation,฀1000฀Park฀Drive,฀Lawrence,฀

PA฀15055-1018฀฀•฀฀Web฀site:฀www.blackbox.com฀฀•฀฀E-mail:฀info@blackbox.com

Customer

Support

Information

฀ACX048฀ACXIO8-C฀ACXSFPC฀ACX288-PS฀

฀ACX080฀ACXIO8-SM฀ACXSFPS฀ACXC16฀

฀ACX160฀ACXIO8-SPF฀ACX080-PS฀ACXC32

฀ACX288฀ACX288-CTL฀ ACX160-PS฀ACXC48

Page 2

724-746-5500 | blackbox.com

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks, and

ServSwitch is a trademark, of BB Technologies, Inc.

Mac is a registered trademark of Apple Computer, Inc.

IBM is a registered trademark of International Business Machines Corporation.

Java is a registered trademark of Oracle Corporation.

TOSLINK is a registered trademark of Toshiba Corporation.

Any other trademarks mentioned in this manual are acknowledged to be

the property of the trademark owners.

NOTE: The ServSwitch DKM FX and the ServSwitch DKM FX Compact function in

similar ways. The difference between them is described in the table below.

Table 1. ServSwitch DKM FX and DKM FX Compact comparison.

ServSwitch DKM FX Compact ServSwitch DKM FX

Number฀of฀Ports16-, 32-, 48-port options 48-, 80-, 160-, 288-port options

Type฀of฀PortsCATx I/O ports only CATx/fiber I/O ports dependent on I/O card

Form Factor Small form factor (1U) Large form factor (4U+)

Modular or Not Not modular Modular

Produkspesifikasjoner

Merke:	Black Box
Kategori:	Bryter
Modell:	ACX048
Vekt:	8900 g
Bredde:	483 mm
Dybde:	231 mm
Høyde:	133 mm
LED-indikatorer:	Ja
Pakkevekt:	9071.85 g
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
AD-adapter utgangsstrøm:	30 A
Bærekraftsertifikater:	RoHS
I/O-porter:	2 x USB Type A F, 1 x DVI-D F, 1 x RJ-45 (1000BASE-TX), 1 x DB9 F (RS-232)
Rack-kapasitet:	4U
Antall slots/porter:	48
Pakningsstørrelse (BxDxH):	368.3 x 558.8 x 241.3 mm
