Side 1/2

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

February 2010

MT1000A-85-R4

BL A C K B OX

Siren sounds at 100 ±3 dB at 100 cm.

Supports maximim cable runs of up to 1000 feet (304.8 m).

Can be triggered by any other sensor connected to the AlertWerks Hub.

AlertWerks

™

Siren and Strobe Light

EME1SS-005

Overview

The combined siren and strobe light sensor adds eye-catching

visual and audio alarms to the AlertWerks Hubs. When trig-

gered, the siren generates a loud alarm sound and the strobe

light flashes brightly, alerting you to an alarm condition.

The siren and alarm are incorporated into one device. Connect

up to two sirens and strobes to the intelligent sensor ports on

the hub (EME108A, EME134A) or hub expansion module

(EME1X8). Each device comes with a 5-foot (1.5-m) CAT5

cable. You can connect the siren/strobe light using up to

1000 feet (304.8 m) of your own CAT5 cable, positioning the

sensors in hot spots.

When you plug a combined siren/strobe light into the intelli-

gent sensor port, the base unit will also detect the sensor. It

displays the device’s status. You can trigger the siren/strobe

light manually via the Web interface or you can configure it to

turn on at certain times.

To continue, turn this page over…

Specifications

Communications Cable — RJ-45 jack to sensor using UTP

CAT5 cable

Alarm Sound —100 ±3 db @ 100 cm

Light Source — (8) super bright LEDs

Maximum Extension Cable Length — 1000 ft. (304.8 m)

with approved low-capacitance shielded cable or UTPl

Measurement Range — Alarm or normal

Measurement Rate — Multiple readings every second

Maximum Number of Sensors Used — Up to (2) sensors

per AlertWerks Jr. (EME102A), and up to (8) sensors per

ServSensor Hub (EME108A) or V4E (EME134A)

Sensor Type — Open/closed contact switch

Strobe Flash Frequency — 400 times/minute

Power — Powered by the AlertWerks Hub. No additional

power is needed.

Size — 4.8"H x 2.8"W x 1.8"D (12.3 x 7.2 x 4.5 cm)

BL A C K BOX

FREE, live, 24/7 Tech Support is just 30 seconds away.

724-746-5500 | blackbox.com

and the Double Diamond logo are registered trademarks, and AlertWerks is a trademark, of BB

Technologies, Inc. Any third-party trademarks appearing in this publication are acknowledged to be the property of their respective owners.

EME1SS-005, version 1

The device can be triggered by any sensor connected to an AlertWerks hub (EME108A) or V4E (EME134A), or by an alarm

condition generated by the base unit. You can fully integrate it with the sensor notification matrix on the V4E (EME134A). Each

device has its own SNMP OID so that status can be collected over the network. You can also control the siren and strobe via

SNMP across a network.

SNMP Commands

Control the sensor manually using the following SNMP commands:

snmpset -m all -v 1 -c <community> <IPaddress>.1.3.6.1.4.1.3854.1.2.2.1.18.1.25<port>|<option>

Options include:

1 = allow-sensor control

8 = cycle-On-Off-On

7 = cycle-Off-On-Off

3 = turn-on

4 = turn-off

Produkspesifikasjoner

Merke:	Black Box
Kategori:	Alarmsystem
Modell:	AlertWerks EME1SS-005
LED-indikatorer:	Alarm
Lysalarm:	Ja
Dimensjoner (B x D x H):	45 x 123 x 72 mm
Produktfarge:	Red, White
Modell/Type:	Kablet sirene
Lydstyrke på alarm:	100 dB
Blinkefrekvens (ganger per minutt):	400
