Side 1/14
ATTENTION! The model SLED177i strobe light is designed to notify hearing impaired
individuals of impending danger. The strobe light has no detection means and MUST be
used in conjunction with operating and interconnected Smoke, Heat, or Carbon
Monoxide Alarms.
The model SLED177i AC wire-in Strobe light can be directly interconnected with Kidde
Safety 3-wire Smoke, Heat and CO alarms. It will produce an intermittent strobe flash
pattern (approximately 4 flashes, followed by approximately 5 seconds off) when trig-
gered by a Carbon Monoxide alarm and a flash every second when triggered by a
smoke or heat alarm.
Thank you for purchasing this strobe light. It is an important part of your family’s home
safety plan. You can trust KIDDE Safety to provide the highest quality safety products.
We know you expect nothing less when the lives of your family are at stake.
For model: SLED177i
1102-7201-00
Strobe
Light
For your convenience, write down the following information. If you call
our Consumer Hotline, these are the first questions you will be asked.
Strobe Light Model Number
(located on back of alarm):
Date Code (located on back of device):
Date of Purchase:
Where Purchased:
SLED177i
Strobe Light User Guide
1102-7201-00_Rev.A_EN_V8:_ 2013.5.28 9:45 AM Page 1
IMPORTANT! READ ALL INSTRUCTIONS BEFORE INSTALLATION AND SAVE
THIS USER GUIDE FOR FUTURE REFERENCE
WARNING! THIS VISUAL SIGNALING DEVICE HAS NO DETECTION
MEANS. IT MUST BE USED IN CONJUNCTION WITH OPERATING AND
INTERCONNECTED ALARMS.
WARNING! DO NOT TRY TO REPAIR THIS STROBE LIGHT YOURSELF
REFER TO THE INSTRUCTIONS IN SECTION 11 FOR SERVICE.
WARNING! DISCONNECTING OR LOSS OF AC POWER WILL RENDER
THIS SIGNALING DEVICE INOPERATIVE.
WARNING! THIS STROBE LIGHT IS EXTREMELY BRIGHT. DO NOT LOOK
DIRECTLY AT THE LIGHT WHEN THE LIGHT IS FLASHING..
CONTENTS OF THIS USER GUIDE
1 -- SPECIFICATIONS
2 -- APPLICATIONS
3 -- RECOMMENDED APPLICATIONS OF STROBE LIGHTS
4 -- LOCATIONS TO AVOID
5 -- INSTALLATION INSTRUCTIONS
6 -- OPERATION AND TESTING
7 -- MAINTENANCE
8 -- LIMITATIONS OF SIGNALING DEVICES FOR THE HEARING IMPAIRED
9 -- GOOD SAFETY HABITS
10 -- NFPA PROTECTION STANDARD 72
11 -- SERVICE AND WARRANTY
!
!
!
!
1102-7201-00_Rev.A_EN_V8:_ 2013.5.28 9:45 AM Page 2
1. SPECIFICATIONS
Model Number: SLED177i ( 3 WIRE INTERCONNECT UNIT )
Electrical Rating:
Regulated 120VAC (96-132VAC)
Maximum Operating RMS Current 630 mA
Multiple station (24) interconnect unit, interfaces directly with Kidde
Safety:
Ion Smoke Alarm Models: 1235, 1275, 1276, 1285, i12020, i12020A
i12040, i12040A, i12060,i2060A, i4618,
i4618A, KN-SMFM-I, RF-SM-ACDC
Photo Smoke Alarms: PE120, P12040,
Photo / Ion Smoke Alarms: Pi2000, Pi2010,
Heat Alarm Models: HD135F,
CO / Ion Smoke Alarm Models: KN-COSM-I,KN-COSM-IB,
KN-COPE-I,KN-COSM-IC,
CO / Photo Smoke Alarm Models: KN-COPE-I,
Carbon Monoxide Alarms Models: KN-COB-IC,KN-COP-IC
Strobe Light: SLED177i, SL177i
Relay Modules: SM120X, CO120X
Smoke or heat alarm events: Constant 1 flash per second nominal
Flash Rate (CO alarm event): Intermittent 1 flash per second nominal
(approximately 4 flashes, followed by
approximately 5 seconds OFF)
Temperature Limits: 0°C (32°F) to 49°C (120°F)
Mounting: Wall or Ceiling
Applications: Primary Direct or Indirect and Supplementary
Light Output: 177 Candela minimum (on axis
measurement)
1102-7201-00_Rev.A_EN_V8:_ 2013.5.28 9:45 AM Page 3
