24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM

INDUSTRIAL

SWITCH/

CONVERTER

LBH120A-H SERIES AND LMC270A-XX-XX SERIES

USER MANUAL

100

LINK/

ACT

PWR

LINK/

ACT

100

LINK/

ACT

100

LINK/

ACT

PWR

LINK/

ACT

PWR

LINK/

ACT

TABLE OF CONTENTS

NEED HELP?

LE AVE THE TECH TO US

LIVE 24/7

TECHNICAL

SUPPORT

1. 87 7. 8 7 7. 2 269

1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBO X.COM

1. SPECIFICATIONS ........................................................................................................................................................................... 3

2. OVERVIEW ...................................................................................................................................................................................... 5

2.1 Introduction ...............................................................................................................................................................................................5

2.2 Available Models ......................................................................................................................................................................................5

2.2.1 Industrial Switches .............................................................................................................................................................................................5

2.2.2 Industrial Media Converters ............................................................................................................................................................................5

2.3 Features ....................................................................................................................................................................................................5

2.4 What’s Included ........................................................................................................................................................................................ 6

2.5 Hardware Description ..............................................................................................................................................................................6

3. INSTALLATION .............................................................................................................................................................................. 8

3.1 Preparing the Installation Site .................................................................................................................................................................8

3.2 Installation Steps .....................................................................................................................................................................................8

4. OPERATION .................................................................................................................................................................................. 11

APPENDIX A. REGULATORY INFORMATION ................................................................................................................................ 12

A.1 FCC Statement .......................................................................................................................................................................................12

A.2 NOM Statement .....................................................................................................................................................................................13

APPENDIX B. TRADEMARKS/DISCLAIMER .................................................................................................................................. 14

B.1 Trademarks Used in this Manual ..........................................................................................................................................................14

B.2 Disclaimer ...............................................................................................................................................................................................14

Produkspesifikasjoner

Merke:	Black Box
Kategori:	Bryter
Modell:	LBH120A-H-SC
Vekt:	200 g
Bredde:	25 mm
Dybde:	71 mm
Høyde:	109 mm
LED-indikatorer:	Ja
Pakkevekt:	354 g
Inngangsspenning:	12 - 48 V
Nettverksstandard:	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
10G støtte:	Nei
Fiberoptisk kontakt:	SC
Fibertype:	Multi-modus
Produktfarge:	Sort
Pakkedybde:	196.85 mm
Pakkehøyde:	82.55 mm
Pakkebredde:	177.8 mm
Driftstemperatur (T-T):	-25 - 60 °C
Kroppsmateriale:	Plast
Ethernet-kobberkabelteknologi:	100BASE-TX, 10BASE-T
Rack-montering:	Nei
Svitsjtype:	Uhåndtert
Antall Basic switching RJ-45 Ethernet-ports:	4
Basic switching RJ-45 Ethernet ports-type:	Fast Ethernet (10/100)
Strømningskontroll støtte:	Ja
Størrelse på adressetabell:	2048 oppføringer
Ruting/svitsjekapasitet:	- Gbit/s
Strøm over Ethernet (PoE):	Nei
Full tosidig:	Ja
Fibre Channel-porter:	1
Bufferminne pakke:	0.384 MB
Strømbryterbelegg:	L2
Fast Ethernet (kobber)-ports, antall:	4
