Side 1/152

User Manual

This Layer 2 modular rackmount managed Gigabit Ethernet switch

has four module slots that accommodate 8-port 10/100/1000BASE-T RJ-45

and SFP modules, and 4-port 10GE SFP+ and 100-Mbps fiber ST and fiber

SC modules.

LE2700 Series Industrial Managed Ethernet Switches

LE2700A LE2710C LE2721C LE2700LV

LE2700AE LE2711C LE2722C LE2700LV-PS

LE2700UK LE2720C LE2731C

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

724-746-5500 | blackbox.com

Page 2

Trademarks Used in this Manual

We‘re here to help! If you have any questions about your application

or our products, contact Black Box Tech Support at 724-746-5500

or go to blackbox.com and click on “Talk to Black Box.”

You’ll be live with one of our technical experts in less than 60 seconds.

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc.

Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

Disclaimer:

Black Box Network Services shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or

cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black

Box Network Services may revise this document at any time without notice.

Produkspesifikasjoner

Merke:	Black Box
Kategori:	Bryter
Modell:	LE2710C
LED-indikatorer:	FDX, Fan fail, Link, Power, Ring
Nettverksstandard:	IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x
MAC-adressefiltrering:	Ja
10G støtte:	Nei
Multicast-støtte:	Ja
Konsollport:	RS-232
AC-inngangsspenning:	88 - 264 V
Jumbo rammer:	9216
Produktfarge:	Sort
Strømforbruk (vanlig bruk):	43.5 W
Driftstemperatur (T-T):	-40 - 85 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 85 °C
Quality of Service (QoS) støtte:	Ja
Ethernet-kobberkabelteknologi:	10BASE-T, 100BASE-FX, 100BASE-TX, 1000BASE-T
Relativ luftfuktighet under drift (H-H):	5 - 95
Rack-montering:	Ja
Svitsjtype:	Håndtert
Trafikk klassifisering:	Ja
Webbasert administrasjon:	Ja
Antall Basic switching RJ-45 Ethernet-ports:	8
Basic switching RJ-45 Ethernet ports-type:	10G Ethernet (100/1000/10000)
Kan stables:	Ja
Forbedret kabelføring:	Ja
Jumbo Frames-støtte:	Ja
Full tosidig:	Ja
Static port security/statisk portsikkerhet:	Ja
Fast Ethernet (kobber)-ports, antall:	4
