Blustream Custom Pro Matrix Bruksanvisning
Les nedenfor 📖 manual på norsk for Blustream Custom Pro Matrix (32 sider) i kategorien Ruter. Denne guiden var nyttig for 3 personer og ble vurdert med 3.9 stjerner i gjennomsnitt av 2 brukere
Side 1/32
CUSTOMPRO
Custom Pro Matrix
User Manual
RevA5_Custom_Pro_Matrix_User_Manual
02
www.blustream.co.uk | www.blustream.com.au
CUSTOM PRO MATRIX USER MANUAL
Contents
Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions carefully
before connecting, operating or
adjusting this product. Please save /
keep this manual for future reference.
Surge Protection Device
Recommended
This product contains sensitive
electrical components that may be
damaged by electrical spikes, surges,
electric shock, lightning strikes, etc. Use
of surge protection systems is highly
recommended in order to protect and
extend the life of your equipment.
Safety &
Performance Notice
The transmission distances of HDMI
over UTP cables are measured using
TE CONNECTIVITY 1427071-6
EIA/TIA-568-B termination (T568B) of
cables is recommended for optimal
performance.
To minimise interference of the
unshielded twisted pairs in the
CAT5e/6/6a cable do not run the
HDBaseT™ / CAT5e/6/6a cabling with
or in close parallel proximity to mains
power cables.
Do not substitute or use any other
power supply other than the enclosed
unit, or a Blustream approved
replacement.
Do not disassemble either the
Transmitter or Receiver units for
any reason. Doing so will void the
manufacturer’s warranty.
Introduction & Key Features 03
Modular Matrix Options Overview 03
Panel Descriptions - 8x8 Chassis 04
Panel Descriptions - 16x16 Chassis 05
Modular Options - Main Communication Board 06
Modular Options - Input Boards 07 - 08
Modular Options - Output Boards 09 - 11
Automatic Smart Scaling Functionality in CSC 11
Modular Options - Feature Boards 12
Installing Modular Matrix Boards 13
HDBaseT™ Transmitter & Receiver Options 14
Matrix Front Panel Control 15
Advanced EDID Management 16
Terminating CAT Cables for use with HDBaseT™ 16
Understanding the HDBaseT™ Status LED’s 17
Audio Functionality 18
Infrared Distribution 19
Infrared Control 20
Example Schematic - 8x8 Chassis 21
Example Schematic - 16x16 Chassis 22
Specifications, Package Contents & Maintenance 23
Infrared Commands - 8x8 Matrix 24 - 25
Infrared Commands - 16x16 Matrix 26 - 27
RS-232 and Telnet Commands 38 - 30
Certifications 31
Notes 32
