DAC13DB QUICK REFERENCE GUIDE

www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk

DAC13DB

Quick Reference Guide

The Blustream DAC13DB has been designed to convert and downmix embedded

5.1ch Dolby Audio or DTS Audio within an optical or coaxial audio signal into a

stereo 2ch signal available on optical, coaxial and analogue audio outputs.

Introduction

FEATURES:

• Downmixes 5.1ch Dolby Audio and DTS Audio from optical Toslink or coaxial digital audio input signals from a

compatible source device to 2ch stereo audio

• Simultaneously outputs downmixed 2ch audio via analogue, optical Toslink or coaxial digital audio outputs

• Dolby Audio and DTS Audio formats supported:

• PCM 2ch

• Dolby Digital 2ch

• Dolby Digital 5.1ch

• DTS 2ch

• DTS 5.1ch

• Supports audio signals up to 24-bit with sampling rates up to 96kHz

DAC13DB QUICK REFERENCE GUIDE

www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk02

Front Panel Description

1 DC 5V Power Connector - Connect to supplied Blustream 5V/1A DC power supply

2 Power Status Indicator

3 Coaxial S/PDIF Audio Input - Connect to coaxial S/PDIF audio output of source device

4 Input Selection Switch - Select between coaxial or Toslink input signal

5 Toslink Optical S/PDIF Audio Input - Connect to Toslink optical S/PDIF audio output of source device

6 Dolby Input Signal Indicator - Illuminates when a compatible Dolby input signal is detected

7 PCM Input Signal Indicator - Illuminates when a compatible PCM input signal is detected

8 DTS Input Signal Indicator - Illuminates when a compatible DTS input signal is detected

1 L/R Analogue Audio Output – RCA connction outputs 2 channel down-mixed audio

2 Coaxial S/PDIF Audio Output - RCA connection outputs 2 channel down-mixed audio

3 Toslink Optical S/PDIF Audio Output - Toslink connection outputs 2 channel down-mixed audio

Rear Panel Description

1 2 3 4 5 6 7 8

1 32

Produkspesifikasjoner

Merke:	Blustream
Kategori:	Ikke kategorisert
Modell:	DAC13DB
Bredde:	80 mm
Dybde:	91 mm
Høyde:	24 mm
Pakkevekt:	200 g
Sertifisering:	FC, CE, RoHS
Strømforbruk:	1000 mA
Driftsspenning:	5 V
Produktfarge:	Sort
Driftstemperatur (T-T):	-5 - 55 °C
Oppbevaringstemperaturomåde (Celsius):	-25 - 70 °C
Rack-montering:	Ja
Lydutgang (venstre/høyre):	1
Digital koaksialutgang for lyd:	1
Digital optisk lydinngang:	1
Optisk digital lydutgang:	1
Digital koaksialinngang for lyd:	1
Samplingsfrekvenser:	Supports audio signals up to 24-bit with sampling rates up to 96kHz
