Side 1/2
Accuracy
0.2% o full capacity
Power
Four AAA batteries or 9 VDC,
600mA adapter (both included)
Display
Five 0.625"/ 16 mm digits LCD
Construction
Low profile stainless steel platform
with mild steel understructure and
stainless steel/ABS indicator with
wall bracket and desk mount
Operator Keys
On/O/Zero, Tare, Units (lb/kg),
Hold/Print
Capacity
500 lb x 0.2 lb / 500 lb x 5 oz /
250 kg x 0.1 kg
The PS500 Light Capacity Floor Scales provide a low-cost solution for general weighing of any item up to 500
lb capacity. This well-designed low-prole base design with stainless steel top plate and a rugged mild steel
understructure incorporate four load cells with large adjustable anti-slip feet to give a solid base when in use.
The PS500-36 comes with a green rubber mate ideal for vet and other animal weighing applications. 15' of
cable connects the base to the stainless steel indicator which features a clear 0.625" / 16 mm digit, backlit
LCD display. A plastic display bracket also allows the indicator to be quickly and easily wall or bench mounted.
The scales features four simple to operate function keys: On/O/Zero, Tare, Units (lb/kg), Hold. Hold feature
can be set to work both as a general hold or as animal averaging hold to capture weight of a moving animal.
To extend battery life an auto-o feature is standard. Powered by four AAA batteries or the external power
adapter provided. This product has a battery saving feature to auto switch o after two minutes of inactivity
prolonging battery life.
PS500
Compact Light Weight Floor Scale
PS500 Compact Light Weight Floor Scale
Unit: lb, lb/oz, kg
Functions: Weight hold, stable weight indicators with
auto power off
Overload Capacity: Capable of withstanding 150%
capacity of weight without damaging scale
COMM Port: RS-232, bi-directional, full duplex (cable
not included)
Calibration: Front panel accessible
Battery Life: Battery life approximately 20 hours
continuous
Operating Temperature: 41° F to 95° F / 5° C to 35° C
Platform Dimension (L x W x H):
22" x 22": 22" x 22" x 2.7"
559 mm x 559 mm x 51 mm
36" x 22": 36" x 22" x 3.1"
906 mm x 559 mm x 51 mm
42" x 22": 42″ x 22" x 2.7"
1067 mm x 559 mm x 51 mm
Packaging Dimension (L x W x H):
22" x 22": 26" x 24" x 4"
660 mm x 609 mm x 101 mm
36" x 22": 39" x 24" x 4"
965 mm x 609 mm x 101 mm
42" x 22": 44" x 24″ x 4"
1117 mm x 609 mm x 101 mm
Indicator Dimension (L x W x H):
6.5" x 1.2" x 3.2"
165 mm x 30 mm x 81 mm
Platform Overall Height: 37" / 940 mm
Indicator Weight: 10 lb / 4.5 kg
Indicator Packaging Dimension (L x W x H):
9.25" x 7.25" x 3"
235 mm x 184 mm x 76 mm
Indicator Shipping Weight:
PS500-22: 35 lb / 16 kg
PS500-36: 37 lb / 26 kg (includes rubber mat)
PS500-42: 63 lb / 29 kg
Certifications: FCC compliance, ETL power adapter
Options (not included):
Indicator Floor Stand (L x W x H):
13.8" x 13.8" x 1"
350 mm x 350 mm x 25 mm
SpecicationsSpecications
PS500_L_07202-0019.indd
V7 07202-0019
Brecknell is part of Avery Weigh-Tronix. Avery Weigh-Tronix is a trademark of Illinois Tool Works group of companies whose ultimate
parent company is Illinois Tool Works Inc (“Illinois Tool Works:). Copyright © 2025 Illinois Tool Works. All rights reserved. This
publication is issued to provide outline information only and may not be regarded as a representation relating to the products or
services concerned. This publication was correct at the time of going to print, however Avery Weigh-Tronix reserves the right to alter
without notice the specification, design, price or conditions of supply of any product or service at any time.
brecknellscales.com
Part of Avery Weigh-Tronix
®
