WS300
Light Capacity Platform Scales
The WS300 light capacity platform scales provide a low cost solution for general purpose weighing of any
item up to 300 kg capacity.
With 1 part in 6000 resolution these platform scales give a weighing performance of 300 kg x 50 g.
This well designed low prole scale incorporates four full load bridge load cells with self leveling, anti-slip
feet to give a solid base in use.
The generous size weigh platforms are available in either WS300-55 (550 mm x 550 mm) or WS300-90
(900 mm x 550 mm with green rubber mat).
Five metres of cable connects the base to the stainless steel indicator which features clear 17 mm high
LCD display digits. A plastic display bracket is included to enable the indicator to be wall or bench mounted.
Key display features are: on/o, push button tare to enable container weights to be removed and net weight
only displayed; kg/lb switching to give readings in either metric or imperial measures and hold/print, which
allows the weight to be either frozen even when the item being weighed is removed or the weight to be
transmitted to a printer or other peripheral device via the RS-232 port (cable not included).
The scales feature auto zero tracking to automatically compensate for small uctuations in zero such as
a build up of material on the platform. To extend battery life an auto-o feature is standard, with the scale
switching itself o after two minutes of inactivity.
Capacity
300 kg x 50 g
Accuracy
Within 0.1% of full capacity
Power
Four AAA batteries (not included)
or 9 VDC, 600mA adapter
Display
Five digit 17 mm / 0.625" high
with seven segment LCD
Construction
Low prole stainless steel
platform with mild steel understructure,
stainless steel/ABS indicator will wall
bracket and desk mount included
Operating Keys
On/O/Zero, Tare, Units,
Hold/Print
