Side 1/25
1
4x2 HDMI 2.0a Quad-View Video Processor
with 4K2K60 4:4:4 & USB 3.0 FHD Video
Capture Function
User Manual
BG-UHD-QVP-4X2
Safety and Notice
The BG-UHD-QVP-4X2 4x2 HDMI 2.0a Quad-View Video Processor with 4K2K60 4:4:4 & USB
3.0 FHD Video Capture Function has been tested for conformance to safety regulations and
requirements, and has been certified for international use. However, like all electronic equipment,
the BG-UHD-QVP-4X2 should be used with care. Please read and follow the safety instructions to
protect yourself from possible injury and to minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION .................................................................................................................. 1
FEATURES ........................................................................................................................... 1
PACKAGE CONTENTS ........................................................................................................ 2
SPECIFICATIONS ................................................................................................................ 3
HARDWARE INSTALLATION .............................................................................................. 4
CONNECTION DIAGRAM .................................................................................................... 4
PANEL DESCRIPTIONS ...................................................................................................... 5
OPERATION APPROACH .................................................................................................... 6
USB PIN DEFINITION ........................................................................................................ 21
WARRANTY ....................................................................................................................... 22
SECOND YEAR ASSURANCE………..………..………..………..………..………………..23
MISSION STATEMENT………..………..………..………..………..………..………..……..23
