BZBGear BG-UM88-100M Bruksanvisning

BZBGear Ruter BG-UM88-100M

Les nedenfor 📖 manual på norsk for BZBGear BG-UM88-100M (32 sider) i kategorien Ruter. Denne guiden var nyttig for 2 personer og ble vurdert med 5.0 stjerner i gjennomsnitt av 1.5 brukere

Last ned PDF

Side 1/32

BG-UM88-100M-KIT

18Gbps 8 by 8 HDBaseT (100M) Matrix

with ARC Function

CONTACT

1.888.499.9906 | support@bzbgear.com | bzbgear.com

Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future reference.

Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical
spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is highly
recommended in order to protect and extend the life of your equipment.

Table of Contents
1. Introduction. ....................................................................................................................
1

2. Features. ...........................................................................................................................
1

3. Package Contents. .........................................................................................................
2

4. Specifications. .................................................................................................................
2

5. Operation Controls and Functions. ...............................................................................
4

5.1. Matrix Panel. ...........................................................................................................
4

5.2. HDBaseT Receiver Panel. ......................................................................................
6

6. IR Remote .........................................................................................................................
7

7. IR Control System. ...........................................................................................................
9

8. IR Cable Pin Assignment. ...............................................................................................
11

9. EDID Management. .........................................................................................................
11

10. Matrix Audio and RS-232 Introduction. .......................................................................
13

11. Web GUI User Guide. ....................................................................................................
14

12. RS-232 Control Command. ..........................................................................................
22

13. Application Example. ...................................................................................................
29

14. Tech Support. .................................................................................................
Back cover

15. Warranty. ........................................................................................................
Back cover

16. Mission Statement. ........................................................................................
Back cover
