Operator’s Manual
CP7763, CP7773,
CP7763D, CP7773D Series
3/4
& 1
Impact Wrench
WARNING
To reduce risk of injury, everyone using, installing, repairing, maintaining,
changing accessories on, or working near this tool must read and
understand these instructions, as well as separately provided safety
instructions part number 6159948710, before performing any such task.
8940163002 Rev 06
Fig. 1
Fig. 2
Fig. 3 Fig. 4
Air Diagram:
Model
Drive
Torque
Speed Dimension
Air consumption
Weight
Inner hose
diameter
Air inlet
Sound
pressure
L
pA
Sound
power
L
wA
Vibrations
Working Max Average @ load a k
L
W
H
1 2 3 4 5 6 7 8 9 10 11
in.
ft.lbs
N.m
ft.lbs
N.m
rpm
in.
mm
SCFM
Nl/s
lbs
kg
in.
mm
in. dB(A) dB(A) m/s² m/s²
CP7763 3/4"
100 - 950
136 - 1288
1 200
1 627
6 300
8.7*3.5*9.1
220*90*230
7.5
3.5
30 11.6 1/2"
3/8" FEMALE
96 107 10.4 4.2
14.2 5.3 12
CP7773 1"
100 - 950
136 -1288
1 200
1 627
6 300
8.7*3.5*9.1
220*90*230
7.5
3.5
30 12.1 1/2"
3/8"
FEMALE
96 107 10.4 4.2
14.2 5.5 12
CP7763-6
3/4"
(6" ext.)
100 - 950
136 -1288
1 200
1 627
6 300
14.9*3.5*9.1
380*90*230
7.5
3.5
30 13.9 1/2"
3/8"
FEMALE
96 107 10.4 4.2
14.2 6.3 12
CP7773-6
1"
(6" ext.)
100 - 950
136 - 1288
1 200
1 627
6 300
14.9*3.5*9.1
380*90*230
7.5
3.5
30 14.3 1/2"
3/8"
FEMALE
96 107 10.4 4.2
14.2 6.5 12
CP7763D 3/4"
250 - 1070
340 -1450
1 300
1 760
6 600
11.4*3.5*6.5
290*90*165
10.2
4.7
41 14.3 1/2"
1/2" FEMALE
98 109 12.0 3.3
19.3 6.5 12
CP7773D 1"
250 - 1070
340- 1450
1 300
1 760
6 600
11.4*3.5*6.5
290*90*165
10.2
4.7
41 14.5 1/2"
1/2" FEMALE
98 109 12.0 3.3
19.3 6.6 12
CP7763D-6
3/4"
(6" ext.)
250 - 1070
340 - 1450
1 300
1 760
6 600
17.5*3.5*6.5
445*90*165
10.2
4.7
41 16.1 1/2"
1/2" FEMALE
98 109 12.0 3.3
19.3 7.3 12
CP7773D-6
1"
(6" ext.)
250 - 1070
340 - 1450
1 300
1 760
6 600
17.5*3.5*6.5
445*90*165
10.2 41 16.3 1/2"
1/2" FEMALE
98 109 12.0 3.3
4.7 19.3 7.4 12
（-）
（+）
L
H
B & C
A
B
C
A
L
H
