Side 1/12

MX67/MX68 Installation Guide

This document describes how to install and set up the MX67 and MX68 security appliance.

Additional reference documents are available online at: www.meraki.com/library/products.

MX67/MX68 Overview

The Meraki MX67 and MX68 are enterprise security appliances designed for distributed

deployments that require remote administration. It is ideal for network administrators who

demand both ease of deployment and a state-of-the-art feature set. A full overview of the

appliances' features can be found in the MX67 and MX68 Overview and Specifications.

Package Contents

In addition to the MX device, the following are provided:

MX67/MX68 MX67W/MX68W

Power Adapter (No Power Cable) Power Adapter (No Power Cable)

2x CAT5 Ethernet Cables 2x CAT5 Ethernet Cables

Wall Screws and Anchors Wall Screws and Anchors

2x WiFi Antennae

MX67C MX68CW

Power Adapter (No Power Cable) Power Adapter (No Power Cable)

2x CAT5 Ethernet Cables 2x CAT5 Ethernet Cables

Wall Screws and Anchors Wall Screws and Anchors

2x LTE Antennae 2x Attached (Non-Removeable) Hybrid WiFi+LTE Antennae

Front Panels

MX67/67C/67W

MX68/68W/68CW

Status Indicator

The MX67/MX68 series devices uses an LED to inform the user of the device's status. LED patterns and their meanings are described below.

LED Status Meaning

Solid orange

Power is applied but the appliance is not connected to the Meraki

Dashboard

Rainbow Colors The appliance is attempting to connect to Meraki Dashboard

Flashing White Firmware upgrade in progress

Solid White

Fully operational/connected, uplink actively using wired WAN

Solid Purple Fully operational/connected, uplink actively using integrated cellular failover

Back Panels

MX67

Produkspesifikasjoner

Merke:	Cisco
Kategori:	hardware brannmur
Modell:	MX67W
Wi-Fi:	Ja
Tilkoblingsteknologi:	Ledning & Trådløs
Antall USB 2.0-porter:	1
WAN-port:	Ethernet (RJ-45)
Brannmurgjennomstrømning:	0.45 Gbit/s
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	4
Driftstemperatur (T-T):	0 - 45 °C
Harmonisert system (HS)-kode:	85176990
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	IPSec
Relativ luftfuktighet under drift (H-H):	5 - 95
Brannmurskapasitet:	450 Mbit/s
VPN-kapasitet:	200 Mbit/s
VPN-gjennomstrømming:	0.2 Gbit/s
