Side 1/36
Multi Language Quick Guide
UPS
ZEUS01E / ZEUS02E / ZEUS03E / ZEUS04E
ZEUS01ES / ZEUS02ES / ZEUS03EM / ZEUS04EM
ZEUS01EP / ZEUS02EP /
ZEUS03EP / ZEUS04EP
ZEUS01ESP / ZEUS02ESP / ZEUS03EMP / ZEUS04EMP
English
Conceptronic UPS
1. Specications
Capacity :
2 Product overview.
1. LCD Display
2. Power Switch
Press the switch for 2 seconds to
turn the UPS ON or OFF.
3. Led Indicator
This LED is illuminated when the
UPS is working.
1. USB port
This port allows connection and communication from the USB port on the computer to
the UPS unit.
2. Modem/LAN Internet Protection (ZEUS01E/01ES/02E/02ES/03E/04E)
Communication protection ports will protect any standard modem, fax, telephone line,
or network cable
3. Input Circuit Breaker
The circuit breaker provides optimal overload protection.
4. Input power cord
5. Battery Backup & Surge Protected Outlets
Provide battery backup and surge protection. They ensure power is provided to
connected equipment over a period of time during a power failure.
ZEUS01E / ZEUS01ES / ZEUS01EP / ZEUS01ESP (650VA 360W)
ZEUS02E / ZEUS02ES / ZEUS02EP / ZEUS02ESP (850VA 480W)
ZEUS03E / ZEUS03EM / ZEUS03EP / ZEUS03EMP (1200VA 720W)
ZEUS04E / ZEUS04EM / ZEUS04EP / ZEUS04EMP (2200VA 1320W)
English
ZEUS01 / ZEUS 02
Denitions for alarm
LED Status
Alarm
Normal
LED lighting
o
Battery Discharge
Flash once every 30 sec
Beep once every 30 sec
Battery Low
Flash once every 2 sec
Beep once every 2 sec
Overload
Flash once every 0.5 sec
Beep once every 0.5 sec
O charging mode
LED o
o
Fault
LED o
Continuous alarm
Mute setting: The audible alarm can be turned OFF or ON by quickly pressing the
power button twice. The default setting is for the Alarm On. You will hear two short
beeps when the Alarm is turned o.
ZEUS03 ZEUS / 04
Denitions for illuminated lcd indicators
Setting Item
PV mode
Fault
Bat mode: battery capacity
Line mode:
1. Battery charging: cycle lighting
2. Battery full charged: lighting
3. Line mode without charger:
battery capacity
