Side 1/9
5925 Heisley Road • Mentor, OH 44060-1833
KoldCube
3
Refrigerated Cabinet
FL-2379
Rev. 1 (7/19)
Page 1 of 9
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Cabinet model number:
Cabinet serial number:
Authorized Service Agency:
Ph: Fax:
Keep this manual for future reference.
KC-UA-11
KC-UA-11H
OPERATING and MAINTENANCE INSTRUCTIONS
for Cres Cor Refrigerated Cabinet, Models KCUA11 & KCUA11H
5925 Heisley Road • Mentor, OH 44060-1833
KoldCube
3
Refrigerated Cabinet
FL-2379
Rev. 1 (7/19)
Page 2 of 9
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
INITIAL SETUP:
1. Remove all packing material from inside the
cabinet
2. Clean and sanitize the interior of the cabinet. See
Cleaning Instructions on page 4.
3. Install all shelf angles on posts
4. Ensure condensate pan is secured in the back
pocket of the unit with supplied screw, and make
sure drain tube is situated so it will drain into it.
5. Plug “power supply battery charger” into wall
receptacle.
6. Plug in 12V connector into back of KoldCube,
making sure red connects to red and black
connects to black. Either inlet connector can be
used.
7. Move the switch on the power supply battery
charger to ON (I). The light on the charger will
eventually turn red, signifying the battery is
charging.
WARNING: USE ONLY SUPPLIED
BATTERY CHARGER OR CONNECT TO
12VDC SYSTEM NOT EXCEEDING 14.4VDC.
REPLACE CHARGER WITH ONLY GENUINE
CRES COR PART. USING A DIFFERENT
BATTERY CHARGER VOIDS WARRANTY
AND COULD DAMAGE EQUIPMENT OR
CREATE A POTENTIALLY HAZARDOUS
SITUATION.
FIRST TIME OPERATION:
1. Keep unit plugged into wall receptacle, charging.
2. If charger has been plugged in for over 4 hours
(with unit powered OFF) and battery monitor does
not read 100%, it has become un-sync’d. Hold the
+ and – buttons together for 3 seconds to re-sync
to 100%.
3. Press power switch ON. Switch will illuminate and
thermometer will turn on.
4. Thermometer displays internal cabinet
temperature.
5. Pre-cool the cabinet for at least 1 hour before
loading food.
NOTE: DO NOT PUT HOT FOOD INTO
COLD CABINET. UNIT IS INTENDED FOR
COLD FOOD ONLY TO BE PLACED INTO
REFRIGERATED ZONE.
NORMAL OPERATION:
1. Thermometer will always display the temperature
representing the warmest zone of the cabinet.
2. Temperature setpoint has been pre-set at the
factory for optimal operation of the cabinet.
Internal controls will self-regulate the temperature
– no adjustment is necessary.
Model Volts Amps Battery
Type
Battery
Capacity
KCUA11 12VDC 10.5 LiFeP04 38 AH
KCUA11H 12VDC 10.5 LiFeP04 76 AH
Battery Charger 120VAC 3.0 - -
INSTALLATION & OPERATING INSTRUCTIONS
(Continued on Page 3)
5925 Heisley Road • Mentor, OH 44060-1833
KoldCube
3
Refrigerated Cabinet
FL-2379
Rev. 1 (7/19)
Page 3 of 9
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
3. To view the max and minimum temps the cabinet
has been at, follow the below instructions:
a. Press SET button
b. “HI” will be displayed on screen
c. Press SET button
d. Highest value seen will be displayed on screen
e. Press SET button
f. “Lo” will be displayed on screen
g. Press SET button
h. Lowest value seen will be displayed on screen
i. Press SET button to go back to normal
4. This unit is intended to be used as temporary
cold storage/transport. It is designed to operate
whether plugged in or not. For best results, it
is recommended to always pre-cool the cabinet
before use, and to keep unit plugged in and
charging while pre-cooling.
BATTERY:
1. Dierent operating conditions aect battery life
(ambient temperature, pre-cool amount, food load,
usage factor, etc.) but in general, refer to table
below for expected battery life per charge:
KCUA11 3-4 Hours
KCUA11H 6-8 Hours
2. Charge time will vary on operating conditions and
ambient temperature, but in general, refer to the
table below for expected charge times:
KCUA11
Cabinet ON 5 Hours
Cabinet OFF 2-2.5 Hours
KCUA11H
Cabinet ON 10 Hours
Cabinet OFF 4-5 Hours
3. For longest battery life, it is recommended to not let
the battery charge go below 10%. It is OK to leave unit
plugged in after it has reached 100% charge – battery
charger will settle on a voltage that is safe to leave for a
period of time.
4. If storing for a long period of time, it is recommended
to charge unit fully before storing unplugged. Before
using again, charge battery to 100%.
5. This unit is designed for air defrost. Under normal
conditions, there is no need for a defrost cycle, and the
evaporator condensate will drain into the condensate
pan in the back pocket of the unit.
6. Remove the condensate pan in the rear pocket of the
unit and drain daily or as needed. Do not allow the pan
to overow.
7. If unit is located in an extremely hot and humid
climate AND subject to continuous usage AND the
door is open an abnormal amount, a manual defrost
may need to be executed. In the unlikely case this
happens, remove all PHF (any food items that must
stay refrigerated) and place in another refrigerator. Turn
the unit o, open the door, and allow it to warm up
for 30 minutes. The unit is now ready to operate again
normally.
NOTE: EVAPORATOR FAN OPERATES
ONLY WHEN DOOR IS CLOSED. IF DOOR IS
KEPT OPEN FOR AN EXTENDED PERIOD
OF TIME, THE RISK OF ICE FORMING ON
EVAPORATOR COIL INCREASES.
TO TURN UNIT OFF:
1. Press power switch OFF.
OPERATING INSTRUCTIONS, Continued
