How to Install
1. Remove the bottom frame from the top
frame by loosening the 4 flat head screws.
2. Decide the preferred hanging height and
choose the correct length of rods needed.
3. Pass the wires through the rods ,swivel,
screw collar loop and canopy. Screw one
end of rod assembly onto the top frame
and the other end onto the swivel.
4. Raise the fixture up to the ceiling and
install the mounting bar onto the outlet
box.Do the wire connections and secure the
canopy using the collar loop ring.
5. Place the glass shade inside the bottom
frame and secure with the clips.
6. Install the bulb onto the socket. Raise
the bottom frame up to the top frame and
align the holes on them.While one person
hold the frame, the other person tightens
the screws using a screwdriver(not provided)
C
U
Electrical Danger Turn Power off
installed by a licensed electrician
in accordance with the National
All electrical components must be
Electric Code and the appropriate
local electrical codes.
You will need 3- Med.Bulb
40 Watts Recommended 60Watts Max.
USE LED BULBS FOR EXTENDED USE
THIS FIXTURE IS WET RATED
LIGHTING THE WAY FOR SIXTY YEARS
ASSEMBLY INSTRUCTION MODEL #ATL-705-MK-TG

Part Number
Part Numbers
A. (1)-Mounting hardware
B. (1)-Screw collar loop
C. (1)-Swivel
D. (1)-Canopy Ø5"*0.75"
XAR705MKTGCAN5IN
E. (1)-Collar loop ring
F. (3)-Hang rod Ø0.75*12"
XAR705MKTGROD12IN
G. (1)-Hang rod Ø0.75"*6"
XAR705MKTGROD6IN
H. (1)-Top frame
I. (1)-White glass shade Ø13.25"*H7"
XAR703GLA13.25IN
J. (1)-Bottom frame
K. (4)-Flat head screws
H
J
I
K
A
B
E
F
C
Clip
G
D
LIGHTING THE WAY FOR SIXTY YEARS
ASSEMBLY INSTRUCTION MODEL #ATL-705-MK-TG
