DataVideo HBT-10 Bruksanvisning

DataVideo AV ekstender HBT-10

Les nedenfor 📖 manual på norsk for DataVideo HBT-10 (16 sider) i kategorien AV ekstender. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/16

HBT-10

TRANSMITTER

BOX

Instruction Manual

Table of Contents

FCC COMPLIANCE STATEMENT ...................................... 4

WARNINGS AND PRECAUTIONS .................................... 4

WARRANTY ................................................................... 6

S WTANDARD ARRANTY 6......................................................

T Y WHREE EAR ARRANTY ..................................................... 6

DISPOSAL ...................................................................... 7

1. INTRODUCTION ......................................................... 8

F EATURES ........................................................................ 8

2. SYSTEM DIAGRAM 9.....................................................

3. CONNECTIONS ......................................................... 10

R P EAR ANEL ................................................................... 10

F P RONT ANEL ................................................................. 11

4. RS-422 PINOUT ........................................................ 13

5. DIMENSIONS ........................................................... 14

6. SPECIFICATIONS ...................................................... 14

C S ABLE ELECTION ............................................................ 15

SERVICE AND SUPPORT ............................................... 16

Disclaimer of Product & Services

The informaon oered in this instruction manual is intended as a

guide only. At all mes, Datavideo Technologies will try to give correct,

complete and suitable informaon. However, Datavideo Technologies

cannot exclude that some informaon in this manual, from me to me,

may not be correct or may be incomplete. This manual may contain

typing errors, omissions or incorrect informaon. Datavideo

Technologies always recommend that you double check the

informaon in this document for accuracy before making any purchase

decision or using the product. Datavideo Technologies is not

responsible for any omissions or errors, or for any subsequent loss or

damage caused by using the informaon contained within this manual.

Further advice on the content of this manual or on the product can be

obtained by contacng your local Datavideo Oce or dealer .

Produkspesifikasjoner

Merke:	DataVideo
Kategori:	AV ekstender
Modell:	HBT-10
Bredde:	85 mm
Dybde:	131.8 mm
Høyde:	45.2 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
HDMI inn:	1
Produktfarge:	Black, White
Strømforbruk (vanlig bruk):	30 W
Modell/Type:	AV-sender
RJ-45-inngangsporter:	1
Ethernet/bredbåndsforbindelse:	Ja
Maksimal overføring avstand:	100 m
Kabeltyper som støttes:	Cat6
RJ-45-utgangsporter:	1
