Side 1/12

VP-633/ VP-634

VP-633 VP-634

100M SDI REPEATER

(POWERED/ UNPOWERED)

Instruction Manual

Table of Contents

FCC COMPLIANCE STATEMENT ................................................ 3

WARNINGS AND PRECAUTIONS .............................................. 3

W ARRANTY ............................................................................. 5

S W TANDARD ARRANTY................................................................. 5

T YHREE EAR WARRANTY ............................................................... 5

DISPOSAL ................................................................................ 6

CONNECTIONS ......................................................................... 7

SPECIFICATIONS 7......................................................................

TYPICAL CABLE LENGTH PERFORMANCE . 8................................

NOTE ....................................................................................... 9

SERVICE ＆

＆

＆＆ SUPPORT ............................................................ 12

Disclaimer of Product & Services

The information offered in this instruction manual is intended as a guide only. At all times, Datavideo Technologies will try to

give correct, complete and suitable information. However, Datavideo Technologies cannot exclude that some information in this

manual, from time to time, may not be correct or may be incomplete. This manual may contain typing errors, omissions or

incorrect information. Datavideo Technologies always recommend that you double check the information in this document for

accuracy before making any purchase decision or using the product. Datavideo Technologies is not responsible for any

omissions or errors, or for any subsequent loss or damage caused by using the information contained within this manual.

Further advice on the content of this manual or on the product can be obtained by contacting your local Datavideo Office or

dealer.

FCC Compliance Statement

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including

interference that may cause undesired operation.

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not

use liquid or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit may

fall, causing serious damage.

6. Slots and openings on the cabinet top, back, and bottom are provided for

ventilation. To ensure safe and reliable operation of this unit, and to

protect it from overheating, do not block or cover these openings. Do not

place this unit on a bed, sofa, rug, or similar surface, as the ventilation

openings on the bottom of the cabinet will be blocked. This unit should

never be placed near or over a heat register or radiator. This unit should

not be placed in a built in installation unless proper ventilation is -

provided.

7. This product should only be operated from the type of power source

indicated on the marking label of the AC adapter. If you are not sure of the

type of power available, consult your Datavideo dealer or your local power

company.

8. Do not allow anything to rest on the power cord. Do not locate this unit

where the power cord will be walked on, rolled over, or otherwise

stressed.

Produkspesifikasjoner

Merke:	DataVideo
Kategori:	AV ekstender
Modell:	VP-634
Vekt:	100 g
Bredde:	38 mm
Dybde:	107 mm
Høyde:	32 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	1920 x 1080 piksler
Produktfarge:	Sort
BNC-port, inngående:	1
Driftstemperatur (T-T):	0 - 40 °C
Modell/Type:	AV-forsterker
BNC-utgangsporter:	1
Maksimal overføring avstand:	200 m
