Side 1/16
4 Channel
HBT-50T
HDBaseT Receiver
Instruction Manual
2
Table of Contents
FCC COMPLIANCE STATEMENT ...................................................................................................... 3
WARNINGS AND PRECAUTIONS ..................................................................................................... 3
WARRANTY ................................................................................................................................... 4
STANDARD WARRANTY .............................................................................................................................. 4
THREE YEAR WARRANTY ............................................................................................................................ 4
DISPOSAL ...................................................................................................................................... 5
1. PRODUCT OVERVIEW ............................................................................................................. 6
FEATURES................................................................................................................................................ 6
SYSTEM DIAGRAM .................................................................................................................................... 7
2. CONNECTIONS ....................................................................................................................... 8
FRONT PANEL .......................................................................................................................................... 8
REAR PANEL ............................................................................................................................................ 8
3. RS-232/RS-422 PINOUT ........................................................................................................ 11
RS-232 ................................................................................................................................................ 11
RS-422 ................................................................................................................................................ 11
4. FIRMWARE UPDATE ............................................................................................................. 12
FIRMWARE UPGRADE REQUIREMENTS ........................................................................................................ 12
UPGRADE PROCEDURE ............................................................................................................................. 12
5. FREQUENTLY-ASKED QUESTIONS.......................................................................................... 13
6. DIMENSIONS ........................................................................................................................ 14
7. SPECIFICATIONS ................................................................................................................... 15
SERVICE AND SUPPORT ............................................................................................................... 16
Disclaimer of Product & Services
The information offered in this instruction manual is intended as a guide only. At all times, Datavideo
Technologies will try to give correct, complete and suitable information. However, Datavideo
Technologies cannot exclude that some information in this manual, from time to time, may not be
correct or may be incomplete. This manual may contain typing errors, omissions or incorrect
information. Datavideo Technologies always recommend that you double check the information in
this document for accuracy before making any purchase decision or using the product. Datavideo
Technologies is not responsible for any omissions or errors, or for any subsequent loss or damage
caused by using the information contained within this manual. Further advice on the content of this
manual or on the product can be obtained by contacting your local Datavideo Office or dealer.
3
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Warnings and Precautions
1. Read all of these warnings and save them for later reference.
2. Follow all warnings and instructions marked on this unit.
3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a
damp cloth for cleaning.
4. Do not use this unit in or near water.
5. Do not place this unit on an unstable cart, stand, or table. The unit may fall, causing serious
damage.
6. Slots and openings on the cabinet top, back, and bottom are provided for ventilation. To ensure
safe and reliable operation of this unit, and to protect it from overheating, do not block or cover
these openings. Do not place this unit on a bed, sofa, rug, or similar surface, as the ventilation
openings on the bottom of the cabinet will be blocked. This unit should never be placed near or
over a heat register or radiator. This unit should not be placed in a built-in installation unless
proper ventilation is provided.
7. This product should only be operated from the type of power source indicated on the marking
label of the AC adapter. If you are not sure of the type of power available, consult your Datavideo
dealer or your local power company.
8. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord will
be walked on, rolled over, or otherwise stressed.
9. If an extension cord must be used with this unit, make sure that the total of the ampere ratings on
the products plugged into the extension cord do not exceed the extension cord rating.
10. Make sure that the total amperes of all the units that are plugged into a single wall outlet do not
exceed 15 amperes.
11. Never push objects of any kind into this unit through the cabinet ventilation slots, as they may
touch dangerous voltage points or short out parts that could result in risk of fire or electric shock.
Never spill liquid of any kind onto or into this unit.
12. Except as specifically explained elsewhere in this manual, do not attempt to service this product
yourself. Opening or removing covers that are marked “Do Not Remove” may expose you to
dangerous voltage points or other risks, and will void your warranty. Refer all service issues to
qualified service personnel.
