Side 1/8

VP-597

2X6 3G HD/SD-SDI

DISTRIBUTION AMPLIFIER

Instruction Manual

Standard Warranty

•Datavideo equipment are guaranteed against any manufacturing defects for one year

from the date of purchase.

•The original purchase invoice or other documentary evidence should be supplied at the

time of any request for repair under warranty.

•The product warranty period begins on the purchase date. If the purchase date is

unknown, the product warranty period begins on the thirtieth day after shipment from a

Datavideo office.

•All non-Datavideo manufactured products (product without Datavideo logo) have only

one year warranty from the date of purchase.

•Damage caused by accident, misuse, unauthorized repairs, sand, grit or water is not

covered under warranty.

•Viruses and malware infections on the computer systems are not covered under

warranty.

•Any errors that are caused by unauthorized third-party software installations, which are

not required by our computer systems, are not covered under warranty.

•All mail or transportation costs including insurance are at the expense of the owner.

•All other claims of any nature are not covered.

•All accessories including headphones, cables, and batteries are not covered under

warranty.

•Warranty only valid in the country or region of purchase.

•Your statutory rights are not affected.

T Year Warrantyhree

Warranty

For WEEE EU Customers only - Marking

This symbol on the product or on its packaging indicates that

this product must not be disposed of with your other

household waste. Instead, it is your responsibility to dispose

of your waste equipment by handing it over to a designated

collection point for the recycling of waste electrical and

electronic equipment.

• All Datavideo products purchased after July 1st, 2017 are qualified for a free two years

extension to the standard warranty, providing the product is registered with Datavideo

within 30 days of purchase.

• Certain parts with limited lifetime expectancy such as LCD panels, DVD drives, Hard

Drive, Solid State Drive, SD Card, USB Thumb Drive, Lighting, Camera module, PCIe

Card are covered for 1 year.

• The three-year warranty must be registered on Datavideo's official website or with

yourlocal Datavideo office or one of its authorized distributors within 30 days of purchase.

Disposal

The separate collection and recycling of your waste equipment at the time of

disposal will help to conserve natural resources and ensure that it is recycled in a

manner that protects human health and the environment. For more information

about where you can drop off your waste equipment for recycling, please contact

your local city office, your household waste disposal service or the shop where you

purchased the product.

Front Panel

216

PWR

GPI

SOURCE

DC IN

12V

2.8W

SDI OUT SDI IN

PWR

SOURCE

GPI

SDI OUT

SDI IN

DC In Socket

Connects the supplied 12V PSU to this socket.

The connection can be secured by screwing

the outer fastening ring of the DC In plug to the

socket.

Mini USB

USB interface for rmware update; VP-597 center

utility control interface

SOURCE Switch

Selects the SDI input source 1 or source 2.

GPI socket

Used for simple external control. The VP-597 can

be switched the SDI input source 1 or source 2 by

a trigger.

3G HD/SD – SDI Output

BNC connects for SDI Outputs (5, 6).

3G HD/SD - SDI Input

BNC connects for SDI Inputs.

Produkspesifikasjoner

Merke:	DataVideo
Kategori:	Mottaker
Modell:	VP-597
Maksimal oppløsning:	1920 x 1080 piksler
Produktfarge:	Black, White
Strømforbruk (vanlig bruk):	2.8 W
BNC-port, inngående:	2
BNC-utgangsporter:	6
Video tilkoblingstype:	BNC
