Side 1/16

Table of Contents

WARNINGS AND PRECAUTIONS ............................................................................ 3

WARRANTY .......................................................................................................... 4

STANDARD WARRANTY .................................................................................................. 4

WO YEAR WARRANTY .................................................................................................. 4

DISPOSAL ............................................................................................................. 4

PACKING LIST ....................................................................................................... 4

INTRODUCTION.................................................................................................... 5

EATURES ................................................................................................................... 5

OMPATIBLE CAMERA MODELS ........................................................................................ 5

SYSTEM DIAGRAM ............................................................................................... 6

CONNECTIONS AND CONTROLS ............................................................................ 7

MCU-100J

KEYBOARD ................................................................................................. 7

MCU-100J

FRONT PANEL ............................................................................................. 7

MCU-100J KEYBOARD GUIDE ................................................................................ 8

SEVEN SEGMENT DISPLAY AND LEDS ............................................................................... 12

ERSION NUMBER DISPLAY AND LED BACKLIGHT BRIGHTNESS CONTROL ................................. 12

AD-1J CAMERA CONTROL ADAPTOR ................................................................... 12

FIRMWARE UPDATE PROCEDURE ........................................................................ 14

DIMENSIONS ..................................................................................................... 15

SPECIFICATIONS ................................................................................................. 15

SERVICE & SUPPORT .......................................................................................... 16

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use

a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit may fall, causing serious

damage.

6. Slots and openings on the cabinet top, back, and bottom are provided for ventilation. To ensure

safe and reliable operation of this unit, and to protect it from overheating, do not block or

cover these openings. Do not place this unit on a bed, sofa, rug, or similar surface, as the

ventilation openings on the bottom of the cabinet will be blocked. This unit should never be

placed near or over a heat register or radiator. This unit should not be placed in a built-in

installation unless proper ventilation is provided.

7. This product should only be operated from the type of power source indicated on the marking

label of the AC adapter. If you are not sure of the type of power available, consult your

Datavideo dealer or your local power company.

8. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord

will be walked on, rolled over, or otherwise stressed.

9. If an extension cord must be used with this unit, make sure that the total of the ampere ratings

on the products plugged into the extension cord do not exceed the extension cord rating.

10. Make sure that the total amperes of all the units that are plugged into a single wall outlet do

not exceed 15 amperes.

11. Never push objects of any kind into this unit through the cabinet ventilation slots, as they may

touch dangerous voltage points or short out parts that could result in risk of fire or electric

shock. Never spill liquid of any kind onto or into this unit.

12. Except as specifically explained elsewhere in this manual, do not attempt to service this

product yourself. Opening or removing covers that are marked “Do Not Remove” may expose

you to dangerous voltage points or other risks, and will void your warranty. Refer all service

issues to qualified service personnel.

13. Unplug this product from the wall outlet and refer to qualified service personnel under the

following conditions:

a. When the power cord is damaged or frayed;

b. When liquid has spilled into the unit;

c. When the product has been exposed to rain or water;

d. When the product does not operate normally under normal operating conditions.

Adjust only those controls that are covered by the operating instructions in this manual;

improper adjustment of other controls may result in damage to the unit and may often

require extensive work by a qualified technician to restore the unit to normal operation;

e. When the product has been dropped or the cabinet has been damaged;

f. When the product exhibits a distinct change in performance, indicating a need for

service.

Produkspesifikasjoner

Merke:	DataVideo
Kategori:	Fjernkontroll
Modell:	MCU-100J
Kompatibilitet:	JVC GY-HM750, GY-HM890U, GY-HM850UGY-HM650U, GY-HM600U, GY-LS300CHU
Produktfarge:	Sort
Videoopptaksgrensesnitt:	Koblet med ledninger (ikke trådløs)
Egnet for smart telefon:	Nei
