Side 1/16

USB-C™ KVM Switch

to HDMI and DisplayPort

with USB 2.0

Product-No: 11485

User manual no: 11485-a

www.delock.com

User manual

Mode d’emploi

Uživatelská příručka

Manuale utente

Manual de utilizare

Korisnički priručnik

Bedienungsanleitung

Manual del usuario

Instrukcja obsługi

Bruksanvisning

Használati utasítás

Εγχειρίδιο χρήστη

-2-

English

Description

This KVM switch by Delock is a convenient solution for connecting two computers

with USB-C™ DP Alt Mode output to one HDMI and one DisplayPort monitor.

Two monitors can be operated simultaneously at the outputs. By using the button

you can switch between both computers.

Peripheral devices

Furthermore, three USB 2.0 ports for mouse and keyboard or USB storage can

be connected.

Multi-Stream Transport (MST)

The product is a Multi-Stream Transport (MST) hub and supports the extended

desktop conguration of DisplayPort. In Windows, the connected monitors are

controlled individually, and can be combined into one large display.

Specication

• Connectors:

Input:

2 x USB Type-C™ (DP Alt Mode) female

1 x USB Type-C™ female (5 V power supply)

Output:

1 x HDMI-A female

1 x DisplayPort female

3 x USB 2.0 Type-A female

• Switch button

• LED indicator for source

• Maximum resolution (depending on the system and the connected hardware):

1 display: up to 7680 x 4320 @ 30 Hz

2 displays: up to 3840 x 2160 @ 60 Hz

• Functions: Mirrored or Extended (Windows only)

• Metal housing

• Colour: anthracite

• Dimensions (LxWxH): ca. 115 x 54 x 12 mm

-3-

English

System requirements

• PC or laptop with a free USB Type-C™ port and DisplayPort alternate mode or

• PC or laptop with a free Thunderbolt™ 3 port

• Monitor or TV with HDMI connector

• HDMI cable

• Monitor or TV with DisplayPort connector

• DisplayPort cable

• Power source with a free USB Type-A female port

Package content

• KVM switch with USB

• 2 x Cable USB-C™ male to USB-C™ male, length ca. 80 cm

• Cable USB-C™ male to USB Type-A male, length ca. 100 cm (power supply)

• User manual

Safety instructions

• Protect the product against moisture

• Protect the product against direct sunlight

Hardware Installation

Note: For the installation of the hardware all devices should be turned o󰀨.

1. Connect the included USB-C™ cable to the switch (PC1 / PC2) and connect

this cable to your USB-C™ video source.

2. Connect the DisplayPort monitor to the DisplayPort output of the KVM.

Optional: Connect the HDMI monitor to the HDMI output of the KVM.

3. Plug in the USB power cable to a USB Type-A port or power supply.

4. Now connect the cables of the mouse and keyboard to the KVM switch.

5. Connect other USB devices to the USB 2.0 Hub if necessary.

6. Turn on all connected devices.

Operation

By using the button on the top you can switch between the di󰀨erent video

sources.

Produkspesifikasjoner

Merke:	DeLock
Kategori:	Ikke kategorisert
Modell:	11485
Innebygd skjerm:	Nei
Bredde:	115 mm
Dybde:	54 mm
Høyde:	12 mm
Strømkilde:	USB
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Maksimal oppløsning:	7680 x 4320 piksler
Opprinnelsesland:	China
Antall HDMI-porter:	1
Antall DisplayPorts:	1
Antall USB 2.0 Type-C-porter:	3
Videobåndbredde:	144 Hz
Produktfarge:	Antrasitt
HD-type:	8K Ultra HD
Kabler inkludert:	USB Type-A to USB Type-C, USB Type-C to USB Type-A
Pakketype:	Hengende boks
Kroppsmateriale:	Metall
Rack-montering:	Nei
Plugg inn og spill:	Ja
Dataoverføringsfrekvens (maks.):	5 Gbit/s
Video tilkoblingstype:	HDMI/DisplayPort
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports:	3
