Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue models, both without notice or obligation.
Dimensions are for reference only. See current full-line price book or www.specselect.com for finish options and product availability.
Refer to www.specselect.com for individual models. Note: Use this page front and back as a product submittal sheet.
DSP–33T Rev. G Page 8.C.1
Cast Lavatory Wastes
Cast Wheelchair Lavatory Wastes
Specification: (example)
Chrome-plated, open grid, cast brass lavatory waste strainer.
o 33T260
32mm (1-1/4") size P.O. plug with overflow holes, 17 gauge,
19 hole grid pattern.
o 33T260-1
32mm (1-1/4") size C.O. plug less overflow holes, 17 gauge,
7 hole grid pattern.
o 33T260-1DC
Same as 33T260-1 but with drain cover.
Patented
Specification: (example)
o RP5651
32mm (1-1/4") size, chrome-plated metal
mechanical lift waste pop-up. Field installable for
removal or non-removal drain plug.
33T260-1
216mm
(8.5")
216mm
(8.5")
RP5651
203mm
(8.0")
Note: Measurements may vary ± 6mm (0.25")
Approvals:
• CSA certified
• Complies to ASME A112.18.2/CSA B125.2
•
Indicates compliance to ICC / ANSI A117.1
( Contact Delta Representative for State and/or Local Approvals.)
33T290-1
33T290-1DC
A
A
A
Specification: (example)
32mm (1-1/4") size, polished chrome-plated,
offset open grid, cast brass lavatory waste strainer.
o 33T290
P.O. plug with overflow holes, 17 gauge, 127mm (5.0")
centers (See A), 19 hole grid pattern.
o 33T290-1
C.O. plug less overflow holes, 17 gauge, 127mm (5.0")
centers (See A), 7 hole grid pattern.
o 33T290-1DC
Same as 33T290-1 but with drain cover.
Patented
Specification: (example)
32mm (1-1/4") size, polished chromeplated,
offset chain and rubber stopper, cast brass lavatory
waste strainer.
o 33T295
P.O. plug with overflow holes
127mm (5.0") centers. (See A)
33T295
Engineer/Architect Approval
Model Specified:
Approval: Date:
®
®
33T260-1DC
DSP–33T Rev. G
