Side 1/69
2019.07
v1.0
User Manual
DJI DIGITAL FPV SYSTEM
2
©
2019 DJI All Rights Reserved.
Using This Manual
Legends
Warning Important Hints and Tips Reference
Read Before First Usage
Read the following documents before using the DJI
TM
Digital FPV System:
1. DJI FPV Air Unit Quick Start Guide
2. DJI FPV Remote Controller Quick Start Guide
3. DJI FPV Goggles Quick Start Guide
4. DJI FPV Goggles Disclaimer and Safety Guidelines
5. DJI Digital FPV System User Manual
Watch all the tutorial videos on the ofcial DJI website and read the disclaimer to understand your
legal rights and responsibilities. Prepare to use for the rst time by reviewing the quick start guides
and refer to the user manual for more information. If you have any questions or problems during the
installation, maintenance, or use of this product, contact DJI or a DJI authorized dealer.
Video Tutorials
Watch the tutorial videos in the link below, which demonstrate how to use the DJI Digital FPV
System safely: http://www.dji.com/fpv/video
Download DJI Assistant 2 (DJI FPV Series)
Download DJI ASSISTANT
TM
2 at http://www.dji.com/fpv/downloads
DJI Assistant 2 supports Windows 7 (or later) or Mac OS X 10.11 (or later).
Searching for Keywords
Search for keywords such as “battery” and “install” to find a topic. If you are using Adobe
Acrobat Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to
begin a search.
Navigating to a Topic
View a complete list of topics in the table of contents. Click on a topic to navigate to that section.
Printing this Document
This document supports high resolution printing.
3
©
2019 DJI All Rights Reserved.
Warning
Always stay alert when using the DJI Digital FPV System to control an unmanned aerial vehicle (UAV).
Carelessness may result in serious harm to yourself and others.
DJI FPV Air Unit
1. The DJI FPV Air Unit may become hot during or after operation. DO NOT touch the air unit before
it cools down.
2. DO NOT use the air unit for an extended period when the temperature is high or there is poor
ventilation. Otherwise, the air unit may overheat and enter low-power mode, which will affect its
performance. Restart the air unit or wait for it to cool down and exit low-power mode.
3. Make sure that the external power source for the air unit is a lithium battery and within 7.4 - 17.6 V.
Otherwise, the air unit may be damaged and may not work properly.
4. DO NOT connect the power cable with the power GND cable directly or plug or unplug the
cables when the air unit is powered on. Otherwise, the equipment may be damaged and may
not work properly.
5. DO NOT obstruct or twist the antennas of the air unit. Otherwise, the transmission may be
affected or blocked.
6. Follow the instructions in the quick start guide or user manual when installing the air unit.
Incorrect installation may cause the air unit to not work properly.
7. Keep all the electronic devices as far away from each other as possible during installation to
minimize electromagnetic interference.
8. Make sure that all connections are secure and all parts are working properly.
9. Make sure that there are no other transmitting devices in the surrounding area that may
cause interference. DO NOT use the same frequency band as other devices. Otherwise, the
transmission of the DJI Digital FPV System will be affected.
DJI FPV Goggles
1. DO NOT throw or drop the product. Otherwise, it may be damaged. If the product is damaged,
take it to a DJI Service Center for inspection and repair.
2. Keep the lenses away from direct sunlight to avoid screen burns.
3. Only use official DJI power cables and an external power supply that meet the specification
requirements (7.4-17.6 V). Use of improper accessories may lead to product damage, void the
warranty, and even property damage and personal injury.
4. The DJI FPV Goggles may become hotter than normal if used for an extended period. If the
product overheats, turn off the device as instructed to avoid injury or product damage.
5. DO NOT use or store the DJI FPV Goggles in adverse weather conditions or environments with
high levels of humidity or dust.
6. DO NOT attempt to disassemble or modify this product. Unauthorized disassembling or
modication will void the product warranty.
7. To avoid damaging the power cable, do not jerk, knot, sharply bend, or abuse the cable in any
way. DO NOT expose the cable to sources of heat or liquid. Keep children and animals away
from the cable.
