MATRICE 200

V1.4

2018.11

User Manual

Using this manual

Legends

Warning Important Hints and Tips Reference

Before Flight

The following materials have been produced to help users make full use of the MATRICE

200.

1. In the Box

2. Safety Guidelines and Disclaimer

3. Quick Start Guide

4. Intelligent Flight Battery Safety Guidelines

5. User Manual

Watching all the tutorial videos and reading the Disclaimer before flight is recommended.

Afterwards, prepare for your rst ight by using the Quick Start Guide. Refer to this manual for more

comprehensive information.

Watch the video tutorials

Please watch the tutorial video below to learn how to use Matrice 200 correctly and safely:

http://www.dji.com/matrice-200-series/info#video

Download the DJI GO 4 app

Be sure to use the DJI GO

4 app or other apps compatible with DJI aircraft during ight.

Scan the QR code or visit

“https://m.dji.net/djigo4” to download the app.

For the best experience possible, use mobile devices running Android v4.4 or iOS v9.0 or above.

* For increased safety, the ight is restricted to a height of 30 m and distance of 50 m when not connected or logged

into the app during ight, including DJI GO 4 and all apps compatible with DJI aircraft.

Download the DJI Assistant 2

Download and install the ASSISTANT

2 before use.

http://www.dji.com/matrice-200-series/info#downloads

Searching for Keywords

Search for keywords such as “battery” and “install” to find a topic. If you are using Adobe

Acrobat Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to

begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to that

section.

Printing this Document

This document supports high resolution printing.

Contents

Using this manual

Legends 2

Before Flight 2

Watch the video tutorials 2

Download the DJI GO 4 app 2

Download the DJI Assistant 2 2

Product Prole

Introduction 6

Feature Highlights 6

Assemble the Aircraft 6

Preparing Remote Controller 8

Aircraft Diagram 9

Remote Controller Diagram 10

Aircraft

Flight Controller 13

Flight Mode 13

Flight Status Indicator 14

Vision System and Infrared Sensing System 15

Return-to-Home (RTH) 19

Intelligent Flight Modes 24

Flight Recorder 29

Attaching and Detaching the Propellers 29

DJI Intelligent Flight Battery 29

DJI AirSense 35

Aircraft Rear Components 36

Remote Controller

Remote Controller Prole 38

Remote Controller Operations 38

Dual Remote Controller Mode 43

Remote Controller Status LED 45

Linking the Remote Controller 46

Camera and Gimbal

Camera 49

Gimbal 50

Produkspesifikasjoner

Merke:	DJI
Kategori:	Drone
Modell:	Matrice 200
Vekt:	3800 g
Bredde:	887 mm
Dybde:	880 mm
Høyde:	378 mm
Batterikapasitet:	4280 mAh
Innebygd kamera:	Nei
Sammenleggbar:	Ja
Egnet for utendørs bruk:	Ja
Batterivekt:	885 g
Batteriteknologi:	Lithium Polymer (LiPo)
Produktfarge:	Sort
Antall USB-porter:	1
Pakkedybde:	390 mm
Pakkehøyde:	290 mm
Pakkebredde:	790 mm
Antall støttede batterier:	2
Minnekortenhet:	MicroSD (TransFlash)
AC-adapter utgangsspenning:	26.1 V
Batterispenning:	22.8 V
Pakketype:	Boks
Driftstemperatur (T-T):	-20 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 45 °C
Modell/Type:	Kvadrokopter
Batteridrevet:	Ja
Innebygd prosessor:	Ja
Megapiksel:	0 MP
Antall rotorer:	4 rotorer
Batterier medfølger:	Ja
Maksimalvekt (kapasitet):	6.14 kg
Kontstruksjonstype:	Klar-for-å-fly (RTF)
Arbeidsfrekvens:	2400 - 5850 MHz
AC-adapter energitap:	180 W
Mobil utstyr holder:	Ja
Maksimal enhetsbredde:	170 mm
Minnekort-innstikk:	Ja
Løfte-vekt (max):	6140 g
Akselavstand diagonal:	643 mm
Horisontal nøyaktighet for drone:	0.3 m
Vertikal nøyaktighet for drone:	0.1 m
Maksimal stigningshastihet:	5 m/s
Maksimal senkningshastighet:	3 m/s
Maksimum vindmotstand:	12 m/s
Maksimal flyvehøyde:	3000 m
Maksimal flyvetid:	27 min
Maksimum hastighet:	23 m/s
Maksimum rotor vinkelhastighet:	300 °/sek
Maksimal yaw vinkelhastighet:	150 °/sek
Transmitter:	Ja
Styringskontroll funksjoner:	Backward, Downward, Forward, Upward
